Welcome to visit Ronen company! A 16 years' specialized manufacture & supplier.( mesh cutting machine )
Mesh cutting machine is used when line wires are feeding from coils;it cut the continuous finished mesh into the required length for covenient transportation and stock.There are three types mesh cutting machines:primitive mesh cutting machine,precise mesh cuttiing machine,high speed precise mesh cutting machine.
function features:
1. Main driving part: Taiwan AC motor with inverter is employed.
2. Central control unit: programmable central control is used and 20 sizes can be set on the same shaft for auto transfer and cutting.
3. Operating panel: all functions are operated on the 10.4" Taiwan EVIEW LCD touch panel.
4. Motor control system: the central control system is PLC programmable controller.
5. Cutting positioning system: cutting positioning is controlled by Mitsubishi servo motor. The imported high precision ball screw is applied to set the size and the linear slide rail is to bear the load of the cutter seat.
6. Blade feeding positioning system: blade feeding is controlled by Mitsubishi servo motor, and the cutting speed is adjustable in three stages.
7. Auto angle adjustment of circular blade: Mitsubishi servo motor is used to calculate the circular blade angle and the angle change is subject to different materials (the angle change range is ±8°).
8. Quick shaft change system: three kinds of shafts are available and quick change of shafts is applied for different materials.
main technical data:
|
Model |
Mesh width |
Wire diameter |
Material |
Space |
Mesh cutting machine type |
Welded Wire Mesh Welding Machine |
1200 |
1.5-2.4 |
Low carbon steel |
50-200 |
Primitive 1*13 00
|
1200 |
2.3-3.0 |
Low carbon steel |
50-200 |
||
Animal cages mesh machine |
1200 |
2.0-3.5 |
Low carbon steel |
50-200 |
|
1600 |
2.0-3.5 |
Low carbon steel |
50-200 |
Primitive2*1600 |
|
Animal cages mesh machine |
1200 |
2.0-4.0 |
Low carbon steel |
50-200 |
Precise3*1300 |
1200 |
3.0-5.0 |
Low carbon steel |
50-200 |
||
1600 |
3.0-5.0 |
Low carbon steel |
50-200 |
Precise3*1600 |
|
2100 |
3.0-5.0 |
Low carbon steel |
50-200 |
Precise3*2100 |
|
2500 |
3.0-5.0 |
Low carbon steel |
50-200 |
Precise3*2500 |
|
Full automatic reinforcing mesh production line |
|
3.0-5.0 |
Low carbon steel |
50-200 |
High speed and precise 3*2500 |
|
5.0-8.0 |
Low carbon steel, standard construction reinforced |
50-200 |
High speed and precise 6*2500 |
|
|
5.0-12.0 |
100-300 |
High speed and precise 8*2500 |
Note:Our factory also can produce the special size according to the client’s requirement.
picture show:
wooden pallet and plastic package in container
our servers:
1.Maintenance period: one year
2.If the buyers need, we can send our technical staff to the buyers’ place to debug the machine and providing the training in 30 days after the machines arrive at the destination port.
3.The numbers of technical persons: one technical person per machines at most
