Welcome to vist Ron-en company! ( Spring wire production line )
Production process flow:
Wire drawing part: de-coiling-feeding & straightening--shot blasting---vertical type drawing---taking up
Annealing part: decoiling---feeding & straightening (2 traction wheels at upside and downside separately)-- No. 1 feed roller (3 traaction wheels at upside and downside sperately)--induction quenching---water cooling---induction tempering--water cooling---No.2 feed roller (3 traction wheels at upside and downside sperately)---hydraulic shear reversing--coiling (clockwise)
Main technical specifications
Wire diameter range: 13-15mm
Max. tensile strength:1270 Mpa (the highest hardness HRC40)
Coils weigth: 800~2500kg
Heating Speed:
| Specification | Speed |
| 13-15mm | 20m/min |
| 10mm | 30-35 m/min |
| 8mm | 35-40 m/min |
Heating temperature 1050-1080 °c (temperature tolerance within +/-10 °c)
Hardness after quenching HRC56-58 or HRC62-64 (depends on the steel grade)
Annealing temperature: 300-500 °c (tolerance within +/-10 °c)
production line length: within 46m.
Photo shows:
If you have any purchase plan for above production lines, glad to talk details with you.
