Relay For Fiber Transmission

Relay For Fiber Transmission thumbnail-1
Relay For Fiber Transmission photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shaanxi, China
Brand Name:
JZ
Model Number:
JZOR860RII--OTDFB mW
Contact Supplier Request Quote Chat Now
Shaanxi Jizhong Electronics Scien-Tech Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Shenzhen/Beijing/Tianjing
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shaanxi, China
Brand Name JZ
Model Number JZOR860RII--OTDFB mW
Theory Other
Usage Telecommunication

 Optical Relay Station



Usage:



It is suitable for 1310nm relay transmission or front second transmission in the optical fiber communication system,

after receiving the 1310nm or 1550nm optical signal. It can extend the optical fiber transmission distance of the imitation

or digital system.



Characteristics:



1. Adopting exclusive PHILIPS optical receiving module for low noise and low distortion receiving, built-in six-section indication of input optical power.

2. Radio Frequency adopts Philips forward low noise module, with amplification output of the rear power multiplier module. The output mode can choose tap or distribution, and each interface has independent testing point.

3. Relay transmission adopts the original import DFB laser (ORTEL, AOL, XESTON). The rear bank power multiplier output signal provides RF drive level, so that insuring the Non-linear distortion Index of C/N. Meanwhile this device sets up the separate RF input threshold, which has the local input function and also can form the Outdoor Optical Transmitter by itself.

4. The laser operating temperature ATC and APC functions adopt micro-rocessor to control automatically. It can guarantee the best operating function; precise control optical output power and extend working life.

5. Micro-processor software monitors dynamically the crucial parameters of laser output power, bias current, cooling current and power etc. Still, it has LCD all states digital display, failure notice and alarming function as well.

6. The whole power and controlling line with multi-protection circuit, low-consumption and independent feed interface improves the stability and reliability of the device



 Main parameters:



Receiving Parameters

Unit

JZOR860R II

Frequency Range

MHz

47~750/860

Optical Input Power

dBm

-4 ~ +2

Optical Receiving Wavelength

nm

1290~1660

Equivalent Noise Current

PA Hz

8

RF Output level

dBμV

108

Flatness in band of RF

dB

+ 0.5

RF Reflection Loss

dB

≥ 16

Channel Loading Data



84PAL-D

C/N

dB

above 51

C/CSO

dB

above 61

C/CTB

dB

above 65



Transmitting Parameters

Unit

OTDFB  mW

Optical Receiving Wavelength

nm

1310 + 20

RF Input level

dBmV

15 ~ 25

RF Input level

dBmV

25 ~35

C/CTB

dB

>65

C/CSO

dB

>61

C/N

dB

>51

Optical Connector Type

FC/APC or SC/APC

Power Voltage



60VAC or 220VAC (Optional)

RF input level is for independent outside optical transmitter

RF input level is for local input port



Transmission

Optical Power

mw

4~5

6~7

8~9

10~11

12~13

14~15

16~17

18~19

20~21

Transmission

Optical Link

dB

7

9

10

11

12

13

14

15

16
