FTTH Mini Optic Node / Home Node

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shaanxi, China

Brand Name:

Model Number:

JZORH1000-2BIX

Shaanxi Jizhong Electronics Scien-Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/Shenzhen/Ningbo/Tianin

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shaanxi, China

Brand Name JZ

Model Number JZORH1000-2BIX

FTTH Optical Mini Receiver

Function:

JZORH1000-2BIX series of optical receiver is professionally designed for Fiber To The Home (FTTH) of CATV network.

Product Introduction:

1. LED display for input optical power.

2. 5~1000MHz optimal design of the circuit.

3. High-responsivity PIN photoelectric conversion and high working realibility.

4.Advanced optical AGC control , and when there is change within the range of AGC, no change of output level.

5. Excellent working range, it also can work well when -16dbm optical power

6. Advanced power supply conversion, the power consumption is 1.5W, excellent lineality output.

7. Multi-service protection circuit is designed, which makes product much safer and more reliable.

Main technical parameter:

Item	Unit	Index	Remark
Downlink receiving parameters
Forward working bandwidth	MHz	45~1000
Rated input optical power	dBm	-16~+2
AGC range	dBm	-10~-1	customizable
Optical working wavelength	nm	1100~1600	Dual windows
Reflection loss	dB	>45
Equivalent input noise current	PA/	≤8
Optical connector		SC/APCor FC/APC	Optional
Flatness in band	dB	±0.75
Output reflection loss	dB	≥14
Link C/N	dB	>43	OMI=3.5%,59 way PAL-D analog tv channel, test when input optical power is -9dBm
Link C/CSO	dB	>60
Link C/CTB	dB	>65
Classic output level	dBμV	84
RF output port		Ftype standard interface
Power supply adapter
Input voltage	V	100~240	AC
Output voltage	V	12	DC
Machine paramenters
Working tempreture	℃	-25~+55
Store tempreture	℃	-40~+65
Relative humidity	%	Max. 95 ,no cooling
MTBF	h	80000
Power consumption	W	1.5	Include no adater
size	mm	76×63×30	Include no input and output port
