DCR-800H digital STB is a kind of high quality transformation digital terminal product, which based on Hi3110Q
chip platform and integrated with advanced QAM demodulation and MPEG-II decoding technology.
It shall receive and decode all the CATV digital TV programs which is compatible
with DVB/MPEG,
support many CA system, meet the demand of descramble and view for encrypted and
unencrypted programs.
And it support EPG, by which the users shall watch and book programs;
support data broadcasting and block information business, which supply lots of appreciation space for operators;
support Mosaic, which supply program guide to users;
support VOD, which make it convenient for users
to watch favourite programs real time.
Friend UI and quick program switching enable the use more humanity
and convenient.
Features of our products:
1.conform with the standard of DVB-C/MPEG-II
2.support multi-level QAM demodulation mode (16QAM,32QAM,64QAM,128QAM,256QAM)
3.support many CA system(Irdeto,Novel-Tongfang,CONAX,Sanzhou Centrino, etc)
4.support multi-way channel search: full frequency range,manual,NIT, etc. Shall be set in priority.
5.support standard EFG, realizable of the management for week information and program book
6.support many data broadcasting system(I-panel,Jiachuang) and stock information system(Hi-tech Road)
7.support standard Mosaic and NVOD
8.support multimode sorting ,OSD and E-mail receiving and screen display
9.support real stand-by, low power consumption
10.with the character of editable, collected and locking of channel management, and support parental lock
11.self-adaption of PAL/NTSC, support transformation between 4:3 and 16:9
12.optional for Chinese and English, convenient for humanization operation
13.with the function of power down program memory, available for separate set of program volume and
sound channel
14.embedded with Chinese secondary word stock, support standard word stock of GB2312, GB13000
15.supply with many intelligent game to add entertainment function
16.support software serial port upgrade, manual and auto mode of Loader over the air upgrade,
shall update the latest edition on line at real time
Technical parameter:
1.Microprocessor and memory
CPU processor |
Processor performance 270MIPS@252MHz |
EEPROM |
8 Kbyte |
Flash memory |
8MByte |
DDR SDRAM |
32 MByte DDR |
2.Tuner(TUNER model:THOMSON-DCT70701)
Input Frequency |
110~858MHz |
Input Resistance |
75Ω |
Input Level |
40~80dBuV (64QAM) |
RF Input/Outputconnector |
IEC 169-1 female/male,75Ω |
3.Demultiplexer (standard:conforming the standard of ISO/IEC13818-1)
Input max Code rate |
Parallel: 13.5Mbyte/s;serial: 120Mbit/s |
PID SLOT |
32 |
4.Video decoder (standard:ISO/IEC13818-2 MPEG-2MP@ML)
Video format |
Support 4:3 and 16:9 |
Video system |
PAL/NTSC self-adaption |
Decode mode |
Full hardware decode |
5.audio decoder
Standard |
ISO/IEC13818-3 |
Audio decoding |
MPEG-1&MPEG-2 Layer I and II |
Channel mode |
Single channel/dual channel/stereo |
6.power supply parameter
Input voltage |
AC110~250V,50/60Hz |
Power consumption |
≤6W |
JI ZHONG DIGITAL COMMUNICATION CO., LTD locates in Hi-tech New Industrial Zone No.1. It is a Hi-tech enterprise which provides researching, manufacturing, managing and serving as a whole.
Our structure and team.
technical researching department,
soft ware researching department,
testing department,
producing department,
quality control department and marketing department.
Besides it owns various manufacturing environment:
several advanced full-automatic and visual imported production line, full-auto infrared carried current welding production line, auto-finished plug-in card production line, production line of full-auto multi-temperature welding in peak wave, full-auto circled assemble production line and 200 sq. m. high-low voltage and high-low temperature aging room.
The main products are digital front part basic hardware, digital TV Set-Top-Box(STB), digital TV operation support software, of which includes MPEG-2 single and multi-way compressed encoder, TS receiver, trans-current multiplexer, data Scrambler, QAM modulator, QPSK modulator, transmit flow distributor, net adapter, DVB-S digital STB, DVB-C digital STB, DMB-T ground wireless STB, CAS (conditional access system), SMS (subscriber management system), DBS(digital broadcast system)
