HX-500 high pressure sealing machine
HX-500 pressure lost circulation perfusion type pressure perfusion machine by foreign manufacturers of machinery industry coordinated, precision design and R & D and humanized use considerations portability and lightness, to special tenacity wear-resistant material to create a solid and durable, eliminate previous infusion of small machines, although the light, damage rate is very high, difficult maintenance, small problems many shortcomings, the company to rapid assembly and disassembly, easy maintenance for the demands and the design structure of perfusion sealing and fill the cracks strong professional models, pressure overload, high pressure perfusion of the body parts of the same type, light weight, can solve the construction to bring with the inconvenience of heavy machinery, professional waterproof and fill the cracks strong construction of Dujiangyan City best weapon.
Fast construction: within a few seconds to 5000PSI working pressure, compared with other types of perfusion time fast.
Light weight: body weighs only 5 kg, with saving easy to move.
Simple repair: no special training required repair, and avoid downtime due to mechanical repair.
Durable: the maximum pressure 10000PSI when the body parts of the same type.
Continuous pressure: the drug can be effectively filled to the depths of fine cracks and honeycomb, it is effective to fill the structural cracks and honeycomb.
Applicable materials: PU foaming stopper, epoxy resin, no material of low viscosity liquid.
Application of HX-500 high pressure sealing machine:
Seepage of concrete structure leakage reinforcing engineering, underground room, the floor, the second construction seam, subway, tunnels, dams, continuous wall, small hive, empty nest, telescopic WEL, ring and post pouring belt cracks etc. leakage stopping projects such as; improve the site, harbor construction, floors and other reinforcement engineering.
Mechanical characteristics:
1 ring: good mechanical performance, no noise, no pollution.
2 simple: small size, light weight, easy to carry, easy to operate.
3 high efficiency: advanced technology, time saving, labor saving, high efficiency.
4 safety: technology, reasonable structure, safe use.
5 high pressure: grouting pressure 0-10000, the concrete structure in the micro gap, micro cracks, micro pores, capillary fill plug.
6: Nondestructive grouting is directly installed on the needle grouting watertight concrete crack, not tick groove, not on the structure of buried pipe, nondestructive.
7: with water plugging of gap leakage, honeycomb leakage, underground water gushing, directly with water grouting.
8 sets: the use of materials such as: polyurethane, epoxy resin, acrylic resin, etc..
9 power: a machine with more, plugging grouting, consolidation grouting, filling grouting, grouting.
10 durable: simple maintenance, convenient maintenance, strong and durable, easy to clean.
Two. Performance indicators:
Single phase AC 220 V / 50 Hz
Pump pressure flow: 0--60MPa / 2.8 L / min
Machine weight: 6kg
Three, the standard parts of the machine:
1 fuselage
2 cup a
Five 3 meter high pressure tube
4 switch valve one. (with the butter head)
5 rubber pad 5
6.Metado sb560 (220V) a drill
7 repair kit
8 filter
HX-500 high pressure sealing machine used in the use of:
The position of the switch is out of (off) for the confirmation of the electric drill.
When using the new machine, please use the lubricating oil in the machine to open the power cycle. The body and the surrounding equipment with a soft cloth dipped in lubricating oil wipe again. PU foaming water plugging agent or epoxy resin mixing evenly into the cup, lid tightly. Perfusion valve wrench to open (opened) and perfusion butter nozzle alignment trash, turn on the power switch, will pipe residual oil extrusion to the slurry ejected so far. Lubricating oil is not an adhesive slurry in the body and equipment to prevent clogging and lubrication.
The perfusion butter nozzle alignment filling head used in tight Fuzheng, first open perfusion switch, then open switching power supply, the slurry continuous pressurized injection structure in slurry so far from the surface overflow, to close the power switch, and then close the perfusion switch, valve swing loosely pulling out. After the completion of the construction must be immediately with a professional cleaning agent into the feeder in the cup, tube residual slurry extrusion to the cleaning agent sprayed so far, perfusion switch insertion in the cup, switch continuity switch several times, so that the inner wall of the pipe produced stress and easy to clean, about 3-5 min after cleaning, machine cleaning agent is sprayed in the trash. After spraying, then apply lubricating oil pour in the perfusion machine cycle again, maintenance, avoid slurry residue machine tube wall, leading to blockage.
Such as pipe just perfusion single liquid PU foaming agent, the next day to construction, the cup leave some or half slurry, the lid tightly, the butter nozzle with a needle in tight, use the next day, in the material cup surface hardening films can be cleaned using, if several consecutive days when not in use, must be clean and maintenance.
Note:
Reperfusion, please wear protective activities (such as gloves, masks, goggles), avoid direct contact with the skin, such as stained slurry please promptly rinse with water, eyes to MIS touch this product should first rinse with plenty of water immediately rushed to the hospital.
Troubleshooting of HX-500 high pressure sealing machine
Operation of electric drill and electric drill from the fixed seat
Reason: drill running direction error, on the contrary.
Methods: drill adjustment to R (forward) position, re drill carefully installed back drill fixing seat, confirm electric drill and electric drill seat is fixed internal gear engagement right, lock the screw can be.
Drill the fixed seat and the fuselage joints loose
Reason: filling machine for working environment, leading to vibration body operation, the drill fixed seat screw loose.
Methods: the drill out, to universal clamp fixed axis, remove the drill is fixed inside the base counter gear, then the drill fixed seat screw locking
