Specifications
High Quality Circular Vibrating Sieve1.Good Efficiency
2.ISO9001 Certification
3.Fine Granularity
Circular Vibrating Sieve Introduction
Circular vibrating sieve is a kind of advanced screen equipment, which is based on the tradition screen and improved by our engineers with imported foreign advanced tenology. And YZS vibrating screen is our company's finest circular vibrating screen.
Circular Vibrating Sieve Application
Circular vibrating sieve used for separating the stuff, are unique and advanced products of our company. They are mainly used in coal dressing, metallurgy,mine, power station ,water conservancy project, buiding industry, light industry and chemical industry etc. They are efficient screening machines for the classification of bulk material such as coal, minerals, coke etc.
Circular Vibrating Sieve Working principle
The circular vibrating sieve is composed of mainframe, eccentric bock, screen web,rub spring, electric moror, coupler and some more. It has multilayers and is of high efficiency. The eccentric shaft vibration exciter and partial block help to adjust amplitude, The material drops down along the long line. We have always kept in our minds the choices, preferences and the tastes of our all clients. We will offer you suitable type according to your requirements.
Circular Vibrating Sieve Features
1.The materials drop down the long line, and the machine bears the features of different specifications
2.Taking the partial block as the exciter, which is strong
3.Screen cross-beam and box are connected by strong bolt, which is whith simple structure, and convenient maintenance.
4.With small amplitude, high frequency, large-inclination structure, high efficiency, large capacity, long service life, low power consumption and noise.
5.
5. Circular Vibrating Sieve Specifications
Model |
Screen Spec(mm) |
Layers |
Screen Mesh Size(mm) |
Feed Size(mm) |
Capacity(t/h) |
Power(kw) |
Vibrating Frequency(HZ) |
Double Amplitude(mm) |
2YZS1445 |
4500x1400 |
2 |
5-50 |
≤100 |
45-250 |
11 |
900 |
5-9 |
2YZS1548 |
4800x1500 |
2 |
5-50 |
≤100 |
50-250 |
15 |
870 |
5-9 |
3YZS1548 |
4800x1500 |
3 |
5-50 |
≤100 |
50-250 |
15 |
870 |
5-9 |
2YZS1848 |
4800x1800 |
2 |
5-50 |
≤100 |
50-250 |
18.5 |
870 |
5-9 |
3YZS1848 |
4800x1800 |
3 |
5-50 |
≤100 |
50-250 |
18.5 |
870 |
5-9 |
2YZS1860 |
6000x1800 |
2 |
5-50 |
≤100 |
50-128 |
18.5 |
870 |
5-9 |
3YZS1860 |
6000x1800 |
3 |
5-50 |
≤100 |
50-128 |
22 |
870 |
5-9 |
2YZS2160 |
6000x2100 |
2 |
5-50 |
≤100 |
60-300 |
22 |
730 |
5-9 |
3YZS2160 |
6000x2100 |
3 |
5-50 |
≤100 |
60-300 |
30 |
730 |
5-9 |
2YZS2460 |
6000x2400 |
2 |
5-100 |
≤100 |
100-460 |
37 |
730 |
5-9 |
High Quality Circular Vibrating Sieve
