Specifications
Plaster Machine Gold Circular Vibrating Screen1.structure, strong excitation power
2.High Efficiency
Plaster Machine Gold Circular Vibrating Screen
Specification of Plaster Machine Gold Circular Vibrating Screen
Brief Introduction of Plaster Machine Gold Circular Vibrating Screen YZS Series circular vibrating screens used for separating the stuff, are unique and advanced products of our
company. They are mainly used in coal dressing, metallurgy, mine, power station, water conservancy project,
building industry, light industry and chemical industry etc. They are efficient screening machines for the classification
of bulk material such as coal, minerals, coke etc.
Working Features of Plaster Machine Gold Circular Vibrating Screen 1. circular vibrating screen uses eccentric block to produce strong exciting force.
2. The ore vibrating scree's crossbeam and the main body of the screen are connected with high strength screw bolts. So they have the features of simple structure and easy maintenance.
3. circular vibrating screen adopts tire clutch with capability of flexible connection and stable operation.
4. circular vibrating screen adopts the structure of small amplitude, high frequency, large obliquity to make the screen hold the capability of high efficiency, large handling capacity, long life span, low consumption, little noise.
Principle of Plaster Machine Gold Circular Vibrating Screen
When circular vibrating screen on operation ,first the materials will feed on circular vibrating screen mesh , and the materials will separated uniformly on screen mesh plates . The rolling bearing of circular vibrating screen will stressed by highly mostly shock-type loads . And more , the circular vibrating screen bearing ,while rotating about their own axis ,going a way of circular ,elliptical or linear vibrating motion . This results in high radial accelerations which additionally stress the bearings , and especially the cages considerably. The operating speeds are usually in a very high condition . As a result, the bearing temperatures are up to 20 to 30 degrees Kelvin higher than in normal applications. In addition, considerable misalignments between the bearing locations and considerable shaft deflections have to be accommodated.
Specification of Plaster Machine Gold Circular Vibrating Screen
Model |
Screen Spec(mm) |
Laters |
Screen Mesh Size(mm) |
Feed Size(mm) |
Capacity(t/h) |
Power(Kw) |
Vibrating frequency(HZ) |
Double Amplitude(mm) |
2YZS1445 |
4500*1400 |
2 |
5-50 |
≤100 |
45-250 |
11 |
900 |
5-9 |
2YZS1548 |
4800*1500 |
2 |
5-50 |
≤100 |
50-250 |
15 |
870 |
5-9 |
3YZS1548 |
4800*1500 |
3 |
5-50 |
≤100 |
50-250 |
15 |
870 |
5-9 |
2YZS1848 |
4800*1800 |
2 |
5-50 |
≤100 |
50-250 |
18.5 |
870 |
5-9 |
3YZS1848 |
4800*4800 |
3 |
5-50 |
≤100 |
50-250 |
18.5 |
870 |
5-9 |
2YZS1860 |
6000*1800 |
2 |
5-50 |
≤100 |
50-128 |
18.5 |
870 |
5-9 |
3YZS1860 |
6000*1800 |
3 |
5-50 |
≤100 |
50-128 |
22 |
870 |
5-9 |
2YZS2160 |
6000*2100 |
2 |
5-50 |
≤100 |
60-300 |
22 |
730 |
5-9 |
3YZS2160 |
6000*2100 |
3 |
5-50 |
≤100 |
60-300 |
30 |
730 |
5-9 |
2YZS2460 |
6000*2400 |
2 |
5-100 |
≤100 |
100-460 |
37 |
730 |
5-9 |
Plaster Machine Gold Circular Vibrating Screen
