Help CenterTop Brand High Efficiency Quarry Sand Washing Machine
Related Products
-
Gold Quality Sand Washing MachineUS$ 88 - 888,888,888MOQ: 1 Set -
2014 Hot Selling XSD2610 Sand Washing MachineryUS$ 88 - 88,888MOQ: 1 Set
-
Sand Washing Machine From China SupplierUS$ 66 - 666MOQ: 1 Set
-
Artificial Sand Washing MachineNegotiableMOQ: 1 Set
-
High Efficiency China Made Sand Washing MachineryUS$ 66 - 6,666MOQ: 1 Set
Specifications
1.Reasonable structure2.High efficiency and cost effective
3.Little sand loss and water saving
4.Good Quality
Sand Washing Machine:
Usage and Application:XSD Series sand washing Machine is a high-efficiency sand washing equipment adopting wheel-like structure, which works with sand making machine. It can wash the stone powder and impurity from the mixed sand that made by sand making machine, which can improve the sand quality. Sand washing machine is widely used in washing, grading and dehydrating in the industry of stone factories, construction site and quartz sand in glass factory.XL Series Sand washing machine is used for sand washing, separating, and cleaning in the construction of high speed road, high speed railway, hydroelectric project, public works and so on.
Sand Washing Machine with Features:
1. High efficiency, reasonable structure, high capacity and low consumption
2. The bearing device of impeller drive is separated from water and materials in water, which greatly protects the bearing from soaking, sand and pollutants.
3. Compared with the spiral sand washing machine, the loss of medium and fine sand and powder is minimized, and the grade and fineness can meet the required standard
4. Sand Washing Machine with long service life and low maintenance costs.
Sand washing machine working Principle:
The sand and gravel flow into washing launder from feeding launder, churned, overturned by the impeller, the impurity in the sand will be washed away from washing launder. Finally, the clean sand will be lift up by the impeller to finish the washing process. the water will be remained in the launder to be reused.
Basic technical information of sand washing machine:
Model |
Impeller dia. mm |
Feeding size(mm) |
Capacity (t/h) |
Power (KW) |
Weight (kg) |
Dimension (mm) |
XS 2615 |
2600×1500 |
≤10 |
30-80 |
7.5 |
2700 |
3320×2200×2670 |
XS2900 |
2900×1000 |
≤10 |
50-100 |
7.5 |
8100 |
3820×2640×3200 |
XS3016 |
3000×1600 |
≤10 |
80-160 |
18.5 |
4300 |
4500×3206×3480 |
XS3500 |
3500× |
≤10 |
120-600 |
11 |
9900 |
4420×2930×3800 |
Except Sand washing machine,we aslo produce jaw crusher,impact crusher,VSI crusher,sand making machine,stone plant,vibrating feeder,vibrating screen,grinding machine,raymond mill etc.
