2013 Quantitative Grading Machine Vibrating Feeder
- 40 Set / Sets per Month
- Qingdao port Shanghai port
- T/T Credit Card
- Gold mining jaw crusher equipment for sale, stone crusher machine
- First-rate high efficiency SZZ series self-centering vibrating screen with ISO 9001 Certificate
- China leader manufacturer ZHAOXIN high efficiency thickener
- Ore benefication thickener machine, dewatering thickener price
- china high quality center drive thickener, thickening equipment
- Shandong Province high efficiency center drive thickener NZ-12, thickening machine
Product Details
Place of Origin: | Henan, China | Brand Name: | SD | Model Number: | GZD850*3000 |
Condition: | New | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Quantitative Grading Machine Vibrating Feeder1.for automatization ore production line
2.has two types
Quantitative Grading Machine Vibrating Feeder
Introduction of Quantitative Grading Machine Vibrating Feeder Vibrating feeder series have two engines. Users can adjust vibrating frequency of feeder freely so as to
completely control feeding speed of stone material and ensure smooth operation of production line
Application of Quantitative Grading Machine Vibrating Feeder It is generally installed in front of the primary crusher, conveys big blocks continuously and evenly while
removing the dirt and impurities by screen bars. As necessary equipment, it can effectively control the
feeding capacity to match with the capacity of the whole crushing plant. In the Sand-Stone production line, it can send materials to crusher evenly and continuously and at the same time, it
can screen materials roughly. It can be used in these areas such as metallurgical industry, coal mining
industry, mining-selecting, building, chemical and grinding industry, etc.
Working principle of Quantitative Grading Machine Vibrating Feeder There are two eccentric shafts rotating at high speed at the same time from opposite directions, thus the
strong centrifugal force is formed. The component forces of centrifugal force along the vibrating direction
will always overlap each other, then counteract with that of vertical force from vibrating direction, then exciting force along single direction is formed to drive the feeder vibrate along straight line. When
materials are fed into the feeder, they may be thrown up and move like Para curve, then fall down. The
materials will move forward on the slope surface of the feeder.
Features of Quantitative Grading Machine Vibrating Feeder A kind of linear direction feeding equipment. easy to adjust reliable operation. easy maintenance. no pollution
Specifications of Quantitative Grading Machine Vibrating Feeder
Model | Size of Funnel(mm) | Max Feed Size(mm) | Capacity(t/h) | Power(kw) | Weight(t) | Installation Slope | Dimension(mm) |
GZD850*3000 | 850*3000 | 120 | 400 | 7.5 | 3.6 | 5 | 3110*1800*1600 |
GZD960*3800 | 960*3800 | 150 | 500 | 11 | 4.5 | 5 | 3850*1950*1630 |
GZD1100*4200 | 1100*4200 | 240 | 580 | 15 | 5.5 | 5 | 4400*2050*1660 |
GZD1100*4900 | 1100*4900 | 280 | 580 | 15 | 6 | 5 | 5200*2050*1700 |
GZD1300*4900 | 1300*4900 | 450 | 650 | 22 | 7 | 5 | 5200*2350*1750 |
Quantitative Grading Machine Vibrating Feeder
