Home > Electrical & Electronics > Electronic Tube & Transistor > Rectifier Diode > Price of Thyristor Controller 25 Amp 400V

Price of Thyristor Controller 25 Amp 400V

Name: Price of Thyristor Controller 25 Amp 400V
Brand: YZPST
SKU: 117324913
Availability: InStock

Price of Thyristor Controller 25 Amp 400V thumbnail-1

Price of Thyristor Controller 25 Amp 400V photo-1

US$ 2.8 - 3.5 MOQ: 100 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Jiangsu, China

Brand Name:

YZPST

Model Number:

25RIA-04/3

Contact Supplier Request Quote Chat Now

Yangzhou Positioning Tech. Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHAGNHAI

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Jiangsu, China

Brand Name YZPST

Model Number 25RIA-04/3

PHASE CONTROL THYRISTORS

25RIA-04

Product Description

PHASE CONTROL THYRISTORS Stud Version

Features

* Hermetic ceramic -metalseal

* high dv/dt

* tested according to IEC standards

*High surge capability

*Compression BondedEncapsulation for heavy duty operations such as severe thermal cycling

Typical Applications

* DC motor controls

* Controlled DC powersupplies

* AC controllers

ELECTRICAL SPECIFICATIONS

Voltage Ratings

Type number	Voltage Code	V RRM /V DRM , maximum repetitive peak reverse voltage V	V RSM , maximum non- repetitive peak rev. voltageV	I RRM /I DRM max. @ T J =T J max. mA
25RIA..	04	400	500	30
	08	800	900
	12	1200	1300
	14	1400	1500
	16	1600	1700

On-state Conduction

Parameter	25RIA..	Units	Conditions
I T(AV) Maximum average on-state current @ Case temperature	25	A	180° conduction, half sine wave
	85	°C
I (RMS) Maximum RMS on-state current	160	A	180° conduction, half sine wave @ T C = 80°C
I TSM, Maximum peak, one-cycle non-repetitive surge current	350	A	t = 10ms	No voltage reapplied	Sinusoidal half wave, Initial T = T max.
	365		t = 8.3ms
	280		t = 10ms	100% VRRM reapplied
	290		t = 8.3ms
I 2 t Maximum I 2 t for fusing	760	A 2 s	t = 10ms	No voltage reapplied
	710		t = 8.3ms
	490		t = 10ms	100% V RRM reapplied
	470		t = 8.3ms
I2√t Maximum I2√t for fusing	7600	A2√s	t = 0.1 to 10ms, no voltage reapplied
V TM Maximum on-state or forward	1.8	V	pk =750A, TJ = 25°C, t p = 10ms sine pulse
I H Maximum holding current	200	mA	TJ = 25°C, anode supply 12V resistive load
I L Typical latching current	350
