Bevelling Pipe Cutting Machine for Automatic Welding

Bevelling Pipe Cutting Machine for Automatic Welding thumbnail-1
Bevelling Pipe Cutting Machine for Automatic Welding photo-1
US$ 10,000 - 200,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
DP
Model Number:
pipe cutting machine DPFM2442
Contact Supplier Request Quote Chat Now
Luoyang Deping Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin shanghai any port of china
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name DP
Model Number pipe cutting machine DPFM2442
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.pipe cutting machine effficiency is in 2 mm
2.Bevel shape: U, V combained inner,outter bevel shape
3.Dia. tolerance 0.05mm



DPFM SERIES PIPE CUTTING MACHINE   DHPS-E(O) SERIES MOTOR TYPE (DISEL TYPE) HYDRAULIC POWER UNIT
Type PFM2442   Type DHPS-E0680 DHPS-O0680
Product size(L*W*H) 2200*1250*1250   Product size(L*W*H) 2430*1250*1180/2530*1150*1900
Weight (KG) 1800   Weight (KG) 1500
Applicable range 24"-42"   Applicable pipe cutting machine DPFM0612,DPFM1224,DPFM2442,DPFM4060,DPFM6080
Max. applicable wall thickness 30mm   Hydraulic oil tank capacity 500L
Clamping type Internal centering hydraulic expanding mechanism: accurate centering, powerful clamping, safe and reliable   Fuel tank capacity None 150L
Bevel shape V shape,U shape,mixed shap,combined innner and outer bevel shape   Primary motor 55KW None
Beveling accuracy Dimension tolerance ±0.05mm,         Angle tolerance±0.5", Ra1.6   Auxiliary motor 7.5KW None
Beveling efficiency (including auxiliary time) Less than 3 mins   Engine None 125HP
Hydraulic motor SAUER DANFOSS   Primary pump A3H180 from Yuken in Japan
Pipe cutting machine speed 105m/min   Auxiliary pump A10 from Yuken in Janpan
Pipe cutting machine depth 0.2mm-0.6mm   Electric control system Design ingress protection degree IP65, electric control components from world-class brand
Cutter SANDVIK/WALTER   Flexible connection Remote control handle (including 20m cable),power output hose(20m)
Operation system Expanding/release, fast forward/fast backward, working feed, speed adjustment of working feed   Others Oil discharge cooling system of oil pump, oil temperature alarm, motore overloading protection Oil discharge cooling system of oil pump, indicators of oil temperature, water temperature and rotation speed
Working pressure Operating pressure:10-12MPa;               Cutting pressure:0-18MPa
Hydraulic power unit Motor type/Diesel type





bevelling pipe cutting machine for automatic weldingbevelling pipe cutting machine for automatic weldingbevelling pipe cutting machine for automatic welding

bevelling pipe cutting machine for automatic welding
