Zhongye UV series UV flatbed printer adopts Japanese SK print heads, equipped with double servo drivers, 5cm max printing height. Realize the formless, non-contacting, and real-time printing on different kinds of sheet materials and roll materials, such as KT board, PVC board, plexiglass, glass, ceramic, metal, and leather etc. It replace the roll of traditional screen printing technology, and brings to customers the individualized, small-lot, various, and multicolored products, with the output features of speediness, high efficiency and flexibility guaranteed.
After sold service
1.Anytime on line technology support
support
3.send the technician to your place for helping
Technical parameter
| Name | UV1800A |
| Class | ZY-SKUVA series |
| Print technology | Drop-on-demandPiezo electric |
| Printhead | 4/5/7/10/14(spt255/12pl) |
| Print width | 1.80m |
| Print high | 8cm |
| Resolution | 1440dpi max |
| Speed | 2pass 36m/h 4pass 24m/h6pass 10m/h |
| Locating mode | Raster /servo |
| Color | CMYK W LC LM |
| Media width | 1.80m |
| Media handl | Roll to roll Sheet to sheet |
| Media types | KT board;PVC board;Plexiglass board;glass board;ceramic board,tile;metal board;leather and all the roll to roll material like flex banner,mesh,one way vision,vinyl etc |
| Drying system | Uv lamp |
| File format | TIFF,JPEG,Postscript 3,EPS,PDF |
| Working process | Printmon software for windows xp |
| Rip | Photoprint /maintop |
| Power supply | 50hz/60hz 220v(10%)20A |
| Operation environmeng | (Tempperature )18-26(Humidity )40%-70% |
| Dimesion | 3.8m*1.6m*1.4m |
| Weight | 800Kg/1000Kg |
Print head model:SPT255,SPT510,SPT1020
The machine also can install the Epson DX5 print head.
