Home > Packaging & Printing > Printing Machinery > Digital Printing Machine > 2014 Latest UV Digital Printer---Liaoning Zhongye UV Flatbed Printer UVB-EP3822

2014 Latest UV Digital Printer---Liaoning Zhongye UV Flatbed Printer UVB-EP3822

2014 Latest UV Digital Printer---Liaoning Zhongye UV Flatbed Printer UVB-EP3822 photo-1
US$ 41,800 - 43,800 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
China
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Plate Type Flatbed Printer
Place of Origin China
Brand Name ZY
Usage Other, Flatbed Printer
Automatic Grade Automatic
Dimensions(L*W*H) 4.6m*2.2m*1.4m
Weight 1800KG
After-sales Service Provided Engineers available to service machinery overseas

We are professional manufacturer of UV flatbed printers in China. our products have been exported to more than 60 countries such as USA, Brazil, Mexico, Chile, Australia ,UK, Spain, Portugal. Italy. German, Turkey, Russia, Ukraine, India, Philippines, Indonesia Mid-East, South Africa, etc.



Our UV printer can print on KT board, PVC board, Plexiglass board, glass board, ceramic board, tile metal board, leather all flat materials. And also flex banner, mesh, one way vision, vinyl etc. roll materials.



Ink Type: It's uv curing ink, environment-friendly ink.

Characteristics: water-proof, anti-uv, heat-resistance.



The warranty time is 1 year, which means in the first year, the spares (not include the print heads and small spending spare parts) are free to be exchanged or repaired in case of some faults. We can supply technical support any time by email, messager, phone and other available methods. we can sent our technician to your place if you need,but the cost of air tickets/visa/board and loding need to be paid by costomers’s side.



Name:

UVB-EP3822

Class:

UVB series

Print technology:

Drop-on-demand Piezo electric

Printhead:

1/2(Epson DX5)

Print width:

3.50m*2.00m

Print height:

10cm

Resolution:

1440dpi max

Speed:

1head: 2pass 25sqm/h; 4pass 16sqm/h; 6pass 10sqm/h

2heads: 2pass 50sqm/h; 4pass 32sqm/h; 6pass 20sqm/h

Locating mode:

Raster /servo

Color:

CMYK

Media width:

3.80m*2.15m

Media handle:

Sheet to sheet

Media types:

KT board, PVC board, Plexiglass board, glass board, ceramic board, tile metal board, leather and flex banner, mesh, one way vision, vinyl etc.

Drying system:

UV LED

File format:

TIFF,Postscript 3,JPEG,EPS,PDF

Working process:

Printmon software for windows xp

Rip:

Photoprint /maintop

Power supply:

50hz/60hz 220v(10%)20A

Operation enviroment:

(Temperature )18-26(Humidity )40%-70%

Dimension:

4.6m*2.2m*1.4m

Weight:

1800Kg







Strong after sale service and warranty!

More different sizes and models available

Have got CE certificate!



Blake Tian

moble:86-18240068853

skype:lyyfblake
