UVB-EP2514 sdopts Epson DX5 print heads,equip with double servo derivers(Japanese Panasonic or Fuji servo motor and motor driver), It replaces the traditional screen printing technology, and brings to customers the individualized, small-lot, various, and multicolored products, with the output features of speediness, high efficiency and flexibility.
It is specialized in printing sheet to sheet. Media donot move during printing, the print head carriage move left and right and the beam move front and back to finish printing. Because the media donot move during printing, this series UV printers can print heavy sheet materials. Print height reach 10cm maximum
Usage: KT board;PVC board;Plexiglass board;glass board;ceramic board,tile;metal board;leather and all the roll to roll material like flex banner,mesh,one way vision,vinyl etc
The main date
| Name: | UVB-EP2514 |
| Class: | UVB series |
| Print technology: | Drop-on-demand Piezo electric |
| Printhead: | 1/2 Epson DX5 |
| Print width: | 2.50m*1.25m |
| Print height: | 10cm |
| Resolution: | 1440dpi max |
| Speed: |
1 head: 2pass 45sqm/h ; 4pass 28sqm/h ; 6pass :16sqm/h 2 heads:2 pass 20sqm/h ; 4pass 12sqm/h ; 6pass :8sqm/h |
| Locating mode: | Raster /servo |
| Color: | CMYK W |
| Media width: | 2.5m*1.4m |
| Media handle: | Sheet to sheet |
| Media types: |
KT board;PVC board;Plexiglass board;glass board;ceramic board,tile;metal board; flx banner,vinyl,mesh,wall paper,leather and so on (roll to roll and sheet to sheet) |
| Drying system: | UV LED lamp |
| File format: | TIFF,Postscript 3,JPEG,EPS,PDF |
| Working process: | Printmon software for windows xp |
| Rip: | Photoprint /maintop |
| Power supply: | 50hz/60hz 220v(10%)20A |
| Operation enviroment: | (Temperature )18-26(Humidity )40%-70% |
| Dimension: | 3.8m*1.6m*1.4m |
| Weight: | 1000KG |
the model is just for your referrence,we also have other model
Welcome to have a further discussion.
Contact person: Cindy
Skype: cindyzhang30
QQ:2323114275
Mobile: 0086-159-9822-4800
