UV flatbed printer with Seiko print head UVB-SK2514
- 1000 Set / Sets per Month
- Dalian
- T/T D/P D/A Credit Card PayPal
- 2500A cardboard box printing machinery equipment Corrugated cardboard honeycomb cardboard kraft cardboard color inkjet printer
- Top Selling KINGT 1016 Small Flatbed UV Printer For Acrylic KT-board Advertisement sign board printing machine
- Super Discounts KINGT 2513G5 250*130 cm Large Format UV Flatbed Printer Machine Manufacturer Supplier
- OMAJIC digital uv 6090 inkjet printing machine for pen bottle phone case A1 small flatbed inkjet printers
- L1800 DTF Printer Machine
- Wholesale China Printer Black and white multi-function machine N510
Product Details
Condition: | New | Plate Type: | Flatbed Printer | Place of Origin: | Liaoning, China |
Brand Name: | Zhongye | Model Number: | UVB2514 | Usage: | Other, glass,ceramic,metal,leather,wood,KT board, PVC board,ABS board, and so |
Automatic Grade: | Automatic | Gross Power: | 1.5KW | Dimensions(L*W*H): | 3.8m*1.6m*1.4m |
Product Description
UVB-SK2514 sdopts Seiko255 print heads,equip with double servo derivers(Japanese Panasonic or Fuji servo motor and motor driver), It replaces the traditional screen printing technology, and brings to customers the individualized, small-lot, various, and multicolored products, with the output features of speediness, high efficiency and flexibility.
It is specialized in printing sheet to sheet. Media donot move during printing, the print head carriage move left and right and the beam move front and back to finish printing. Because the media donot move during printing, this series UV printers can print heavy sheet materials. Print height reach 10cm maximum
Usage: KT board;PVC board;Plexiglass board;glass board;ceramic board,tile;metal board;leather and all the roll to roll material like flex banner,mesh,one way vision,vinyl etc
The main date
Name: | UVB-SK2514 |
Class: | UVB series |
Print technology: | Drop-on-demand Piezo electric |
Printhead: | 4/5/7/10/12/14(SPT255/12pl) |
Print width: | 2.50m*1.25m |
Print height: | 10cm |
Resolution: | 1440dpi max |
Speed: | 2pass 24sqm/h ; 4pass 16sqm/h ; 6pass 8sqm/h(10/12/14 heads, double speed) |
Locating mode: | Raster /servo |
Color: | CMYK W LC LM |
Media width: | 2.5m*1.4m |
Media handle: | Sheet to sheet |
Media types: | KT board;PVC board;Plexiglass board;glass board;ceramic board,tile;metal board;leather and all the roll to roll material like flex banner,mesh,one way vision,vinyl etc |
Drying system: | UV LED lamp |
File format: | TIFF,Postscript 3,JPEG,EPS,PDF |
Working process: | Printmon software for windows xp |
Rip: | Photoprint /maintop |
Power supply: | 50hz/60hz 220v(10%)20A |
Operation enviroment: | (Temperature )18-26(Humidity )40%-70% |
Dimension: | 3.8m*1.6m*1.4m |
Weight: | 1000KG |
the model is just for your referrence,we also have other model
If you have any question, just contac me freely
Welcome to have a further discussion.
Contact person: Cindy
Skype: cindyzhang30
QQ:2323114275
Mobile: 0086-159-9822-4800
