UV Flatbed Printer UVB-SK2818

UV Flatbed Printer UVB-SK2818 thumbnail-1
UV Flatbed Printer UVB-SK2818 photo-1
US$ 35,000 - 40,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Liaoning, China
Contact Supplier Request Quote Chat Now
Liaoning Zhongye Technology And Industry Development Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Flatbed Printer
Place of Origin Liaoning, China
Brand Name ZY
Model Number ZYUVB-SK2818
Usage Other, Glass, ceramic tile
Automatic Grade Semi-Automatic
Gross Power 3000W
Dimensions(L*W*H) 3.8m*2.0m*1.4m

Specifications

1.printing size 2.5m*1.5m,
2.LED lump,
3. Seiko255/12pl print head,

Name: UVB-SK2818
Class: UVB series
Print technology: Drop-on-demand Piezo electric
Printhead: 4/5/7/10/12/14(SPT255/12pl) The quantity of print head is optional
Print width: 2.50m*1.55m
Print height: 10cm
Resolution: 1440dpi max
Speed: 2pass 24sqm/h ; 4pass 16sqm/h ; 6pass 8sqm/h(10/12/14 heads, double speed)
Locating mode: Raster /servo
Color: CMYK W LC LM
Media width: 2.8m*1.8m
Media handle: Sheet to sheet
Media types: KT board;PVC board;Plexiglass board;glass board;ceramic board,tile;metal board;leather and flex banner,mesh,one way vision,vinyl etc.
Drying system: UV LED
File format: TIFF,Postscript 3,JPEG,EPS,PDF
Working process: Printmon software for windows xp
Rip: Photoprint /maintop
Power supply: 50hz/60hz 220v(10%)20A
Operation enviroment: (Temperature )18-26(Humidity )40%-70%
Dimension: 3.8m*2.0m*1.4m
Weight: 1200KG

UV flatbed printer UVB-SK2818UV flatbed printer UVB-SK2818



Skype: kajia99
Cell phone: +86 13555768580
Tel: +8624 89789511-8006
