Small Size Digital Flatbed Glass Printer
US$ 15,000 - 70,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Liaoning, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian/China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UV Digital Flatbed PrinterUS$ 6,300 - 70,000MOQ: 1 Unit -
uv Flatbed Printer Machine for Glass With White ColourUS$ 10,000 - 14,000MOQ: 1 Set
-
uv Flatbed Printer Machine With White Colour for Glass,ceramic(UVC0906)US$ 10,000 - 14,000MOQ: 1 Set
-
Small uv Flatbed Printer Machine for Glass,ceramic(UVC0906)US$ 10,000 - 14,000MOQ: 1 Set
-
UV Flatbed Printer UVB-SK2818US$ 35,000 - 40,000MOQ: 1 Set
Condition
New
Plate Type
Flatbed Printer
Place of Origin
Liaoning, China
Brand Name
ZY brand
Model Number
uv1309c
Usage
Other, ads printing
Automatic Grade
Automatic
Gross Power
200w
Dimensions(L*W*H)
2.4*1.8*1.2(m)
Specifications
digital flatbed glass printer can print on glass, ceramic, acrylic board, and all other board material| Model | ZY-UV1309C | |
| Print Head | 5(SEIKO255) | |
| Print Width | 1.3m | |
| Resolution | 1440dpi | |
| Speed | 2 pass 18/h | |
| 4 pass 12/h | ||
| 6 pass 8/h | ||
| Color | CMYK W | |
| Dimension | 2.4m*1.8m*1.2m | |
| Net weight/Gross weight | 600kg | |
| Print Technology | Drop-on-demand Piezo Electric | |
| Locating Mode | Raster/Servo | |
| Media Handling | sheet to sheet | |
| Media Types | KT board, PVC board, Plexiglass board, glass board, ceramic board, metal board, etc | |
| Ink | UV inks | |
| Drying System | Uv lamp | |
| File Format | TIFF, JPEG, Postscript 3, EPS, PDF | |
| Rip Software | Photoprint/maintop | |
| Working process | Printmon software for windows xp | |
| Operation Environment | (Temperature)18-26 (Humidity)40%-70% | |
| Power Supply | 50hz/60hz 220v(10%)20A | |
| Motor: Japanese Panasonic, Fuji AC servo Motor | ||
| Rail: Japanese THK, Taiwan HWIN | ||
| Print head cleaning: Positive Pressure, Suction double functions | ||
| Ink supply system: Germany KNF ink supply system, Japanese negative pressure system | ||
Zhongye digital flatbed glass printer UV series flatbed printer adopts Japanese Spt series print heads, equipped with double servo drivers, 8cm max printing height. Realize formeless, non-contacting, and real-time printing on different kinds of sheet materials, such as KT board, PVC board, plexiglass, glass, ceramic, metal, and leather.It replaces the roll of traditional screen printing technology and brings to customers individualized, small-lot, various, and multicolored products, with the output features of speediness, high efficiency and flexibility guaranteed.
