Specifications
Flatbed Printer:UVB 28181, Eption 5th (1/2 heads)
2, panasonic motor equipped
3, real 1440dpi
Name: | UVB-EP2818 |
Class: | UVB series |
Print technology: | Drop-on-demand Piezo electric |
Printhead: | 1/2(Epson DX5) |
Print width: | 2.50m*1.55m |
Print height: | 10cm |
Resolution: | 1440dpi max |
Speed: | 1head: 2pass 25sqm/h; 4pass 16sqm/h; 6pass 10sqm/h 2heads: 2pass 50sqm/h; 4pass 32sqm/h; 6pass 20sqm/h |
Locating mode: | Raster /servo |
Color: | CMYK |
Media width: | 2.8m*1.8m |
Media handle: | Sheet to sheet Roll to Roll |
Media types: | KT board, PVC board, Plexiglass board, glass board, ceramic board, tile metal board, leather and all the roll to roll materials like flex banner, mesh, one way vision, vinyl etc |
Drying system: | UV lamp |
File format: | TIFF,Postscript 3,JPEG,EPS,PDF |
Working process: | Printmon software for windows xp |
Rip: | Photoprint /maintop |
Power supply: | 50hz/60hz 220v(10%)20A |
Operation enviroment: | (Temperature )18-26(Humidity )40%-70% |
Dimension: | 3.8m*2.0m*1.4m |
Weight: | 1400KG |
This series of UV printers is specialized in printing sheet to sheet. Media don't move during printing. The printe head carriage move left and right and the beam move front and back to finish printing. Because the media don't move during printing, this series UV printers can print heavy sheet materials. Print height reach 10 cm maximum.
Zhongye UV series UV flatbed printer adopts Japanese series print heads, equipped with double servo drivers, 10cm max printing height. Realize the formless, non-contacting, and real-time printing on different kinds of sheet materials , such as KT board, PVC board, plexiglass, glass, ceramic, metal, and leather etc. It replace the roll of traditional screen printing technology, and brings to customers the individualized, small-lot, various, and multicolored products, with the output features of speediness, high efficiency and flexibility guaranteed.
| Zhongye UV series UV flatbed printer adopts Japanese series print heads, equipped with double servo drivers, 10cm max printing height. Realize the formless, non-contacting, and real-time printing on different kinds of sheet materials , such as KT board, PVC board, plexiglass, glass, ceramic, metal, and leather etc. It replace the roll of traditional screen printing technology, and brings to customers the individualized, small-lot, various, and multicolored products, with the output features of speediness, high efficiency and flexibility guaranteed. |
LIAONING ZHONGYE (ZY) TECHNOLOGY AND INDUSTRY DEVELOPMENT CO., LTD.
162 Huishan St. Huishan Hi-Tech Development Zone Shenyang Liaoning China 110164
Tel: 0086 24 89789511-8015 Fax: 0086 24 89789357
Contact person: eric lee Skype: eric.lee1103 MSN: eric-zhongyetech at
