Mobile Primary Crushing Units With Jaw Crusher
Working Principle of Jaw Stone Crusher
Motor passes motive power to eccentric shaft end's pulley, making the eccentric shaft under lead of motor do rotatory movement according to the demanded speed rated; Dynamic jaw head propelled by the eccentric shaft's eccentric force makes regular fixed track compressive to break the materials.
Characteristics of Jaw Stone Crusher
1. Big feeding granularity and breaking ration, large capacity.
2. Opration is stable and reliable, fixed with over-loading protective device.
3. Low energy consumption , little wearing spare parts, low maintenance cost.
4. Adjusting parts are reinforced emphatically and finish machining, reduce repair frequence.
5. Axle bearing adopts with Multi-storey labyrinth seal, prolonging operation life.
6.Using modules lubrication, more easier and convenient for maintenance.
7.Adopting belt pulley new locking craft, keyless connection, making mainenance more convenient.
Application of Jaw Stone Crusher
1. Widely applied to all sorts of ore, rock, quarry, etc., the breaking compressive strength not exceeding 320Mpa.
2. Being widely used in mine, metallurgy, roads and bridges, building materials, water conservancy and chemical industry, etc.
Specifications of Jaw Stone Crusher
|
Model |
Feeding port size(mm) |
Max feeding size(mm) |
Adjustable rang of discharge opening(mm) |
Capacity(t/h) |
Power(kw) |
Dimension (mm) |
Weight(t) |
PE-250×400 |
250×400 |
200 |
20-50 |
5-20 |
15 |
1430×1310×1340 |
3 |
PE-400×600 |
400×600 |
350 |
40-100 |
15-60 |
30-37 |
1700×1732×1653 |
7 |
PE-500×750 |
500×750 |
425 |
50-100 |
40-110 |
45-55 |
2035×1921×2000 |
12 |
PE-600×900 |
600×900 |
480 |
65-160 |
90-180 |
55-75 |
2290×2206×2370 |
17 |
PE-750×1060 |
750×1060 |
630 |
80-140 |
110-320 |
90-110 |
2655×2302×3110 |
29 |
PE-900×1200 |
900×1200 |
750 |
95-165 |
220-450 |
110-132 |
3800×3166×3045 |
58 |
PE-1200×1500 |
1200×1500 |
1020 |
150-300 |
400-800 |
160-220 |
4200×3750×3820 |
100.9 |
PEX-250×750 |
250×750 |
210 |
25-60 |
15-30 |
22-30 |
1667×1545×1020 |
5 |
PEX-250×1000 |
250×1000 |
210 |
25-60 |
15-50 |
30-37 |
1550×1964×1380 |
7 |
PEX-250×1200 |
250×1200 |
210 |
25-60 |
20-60 |
37-45 |
2192×1900×1950 |
8.5 |
About Warranty:
Our Warranty is 1 year for whole machine except wearing spare parts.We will provide the technical advice and find the solution immediately for you when the machine is in trouble-shoot. For wearing spare parts, we guarantee the high quality parts for long-time supply.
Our Services
1. We guarantee our reply in 24 hours of working day.
2. Our engineers will communicate with our customers in different languages to help them to solve the technical questions and quality issues.
3. Our professional QA people make strict inspection before shipment.
4. Punctual shipment time and good after-sales service will be guaranteed.
