We are professional manufacturer of UV flatbed printers in China. our products have been exported to more than 60 countries such as USA, Brazil, Mexico, Chile, Australia ,UK, Spain, Portugal. Italy. German, Turkey, Russia, Ukraine, India, Philippines, Indonesia Mid-East, South Africa, etc.
Our UV printer can print on KT board, PVC board, Plexiglass board, glass board, ceramic board, tile metal board, leather all flat materials. And also flex banner, mesh, one way vision, vinyl etc. roll materials.
You can choose 2 print head for double 4 color (CMYK)or one head for 4color (CMYK) and the other head for white color.
Ink Type: It's uv curing ink, environment-friendly ink.
Characteristics: water-proof, anti-uv, heat-resistance.
The warranty time is 1 year, which means in the first year, the spares (not include the print heads and small spending spare parts) are free to be exchanged or repaired in case of some faults. We can supply technical support any time by email, messager, phone and other available methods. we can sent our technician to your place if you need,but the cost of air tickets/visa/board and loding need to be paid by costomers’s side.
UVE3200
Print technology: micro piezo dot-on-demand
print head: 1 group Epson DX5 printheads(paratactic structure)(2groups optional)
4color: CMYK/Servo
Resolution(Max): 1440dpi
Printing width(Max): 3.2m
Media thickness: 2cm
Printing speed: Draft Model: 540*720dpi 36sq.m./h
Production model: 720*720dpi 20sq. m. /h
High quality model: 720*1440dpi 16sq. m./h
Drying system: Front, back heating system(middle heating system is optional), middle flatbed sucker system, PID temperature; UV LED
Media width: 3.2m
Media handle: Roll to Roll; Sheet to Sheet.
Media type: KT board; PVC board; Plexiglass board; glass board; ceramic board, tile; metal board; leather, etc. all flat materials and all the roll to roll materials like flex banner, mesh, one way vision, vinyl,etc.
Inks:uv Inks
Ink Cartridge: 350ml, 8pieces
RIP:Maintop/Photoprint
Form: Tiff, Jpeg, etc.
Operation system: Windows XP/Professional bi-language software(Chinese & English)
power requirement: AC 220-240v 50/60 HZ
Working environment: 1000W(max. power) 300W(normal working power)
Temperature: 20-25°C
Humidity: 40-70%, non condensation
Dimension: 4.4m*0.9m*1.25m
Weight: 460kg/640kg
Strong after sale service and warranty!
More different sizes and models available.
Have got CE certificate!
