Help CenterZY-SK3200FB Solvent Flatbed Printer
Related Products
Specifications
printer Seiko printheads,servo driver,square shape carriage rail.Solvent ink is widely used for KT board etc. & roll materials.
1.Whole steel made drop-on-demand print head, super long life time,255 or 510 nozzles each head.
2.Color range reach up to 6 colors,720 to 144dpi in resolution, super choice for true-color, speed and resolution.
3.Voltage of heads is adjustable to the environment temperature, thus solve the problem of printing fading out of ink which is caused by temperature change
4.Powerful Maintop 5.2B version output software make easy operation, available for printing in two modes
5.Automatically skip the white area of printing, make higher effective
6.Need black only to print black words, no need 3 color or more color combination to make this print
7.Continue-printing system enable printing continue from where the power break-off, enable no waste time in break off period.
8.Aluminum beam for printing, lower noise, enable printing quietly.
9.Allow you to change the parameter of step double direction ,and speed while printing
10.Air sucking system on printing platform enable no scratching of heads and no draping over of media while printing. This make the higher resolution printing realized
11.Ink supply method: Automatic sensor for ink level, consistent ink supply by ink pump, also manual ink supply available
12. Automatic media rolling up and down system
13. Automatic print heads cleaning system, positive pressure cleaning and flushing cleaning available
14. Pre-heating, after-heating system equipped
15. Data transfer port: USB
16. Print head to media distance: 2 to 4mm adjustable
| Name | 3200FB flatbed printer |
| Class | ZY-SKFB series |
| Print technology | Drop-on-demand Piezo electric |
| Printhead | 4/6/8/12(spt510/255) |
| Print width | 3.20M |
| Print high | 5cm |
| Resolution | 1440dpi max |
| Speed | 2pass 60m/h ; 4pass 45m/h ; 6pass 24m/h |
| Locating mode | Raster /servo |
| Color | CMYK W LC LM |
| Media width | 3.2M |
| Media handl | Roll to roll Sheet to sheet |
| Media types | corrugated,foam ore, gatorboard;sintra(PVC), eramic tiles,glass,plexiglass, wood, sheet metal, paper,vinlys, dhesive back vinyls, fabrics |
| Drying system | Solvent/two-year |
| File format | TIFF,Postscript 3,JPEG,EPS,PDF |
| Working process | Printmon software for windows xp |
| Rip | Photoprint /maintop |
| Power supply | 50hz/60hz 220v(10%)20A |
| Operation environmeng | (Tempperature )18-26(Humidity )40%-70% |
| Dimesion | 4.6m*0.7m*1.4m |
| Weight | 600Kg |
More different sizes and models available
Have got CE certificate
