High resolution solvent printer

Specifications

large solvent printer machine,Adopting xaar 382 printheads, cost effective and in high resolution.

ZhongYe XAAR series Large Format Solvent Printer: adopting xaar382 print head, DC motor&raster locating mode, cost-effective and in high resolution up to 1440dpi.The first choice for common customers newly to printing industry.



Name	2500H
Class	ZY-XRH series
Print technology	Drop-on-demand Piezo electric
Printhead	4/6/8/12 (xaar382)
Print width	2.5M
Resolution	1440dpi max
Speed	2pass 70m/h ; 4pass 40m/h ; 6pass 24m/h
Locating mode	Raster /servo
Color	CMYK LC LM
Media width	2.5M
Media handl	Roll to roll
Media types	Flex banner,vinyl sheet,one way vision,mesh,PVC fabrics,paper,etc
Ink	Solvent/two-year outdoor lifetime
File format	TIFF,JPEG,Postscript 3,EPS,PDF
Working process	Printmon software for windows xp
Rip	Photoprint /maintop
Power supply	50hz/60hz 220v(10%)20A
Operation environmeng	(Tempperature )18-26(Humidity )40%-70%
Dimesion	4.0m*0.8m*1.5m
Weight	500Kg/600Kg



Zhongye 250 series large format printer: adopting spt (optional xaar382) printhead, DC motor and raster locating mode, widely used for outdoor printing. Up to 1440dpi resolution, 120m/h speed with 8/12 printheads, it is certain to be the first choice among printer with high resolution and high speed.

  large solvent printer
