Full-automatic Transformation Ratio Meter
1.1 Product introduction
GDBCII is small and light. The test result is precise and reliable. It displays test data in big screen and operates in visual menu. The parameters of all groups of transformation ratio can be measured in one time.
1.2functions
1 Automatically measure transformer connection group
2 Automatically identification group of transformer
3 Automatically switch phase sequence
4 Automatically switch range
5 Automatically checking
6 After input standard ratio. It can calculate error automatically
7 Testing voltages is cut off automatically when one test is finished
8 Set data and the test results are saved automatically. The history data can be checked again.
9 It needs to input transformation ratio only one time when measuring on-load transformer.
1.3Technique Index
1 The measuring range of ratio: 1-10000
2 Measuring groups: 1-12point
3 Accuracy: 0.2class for 1-1000; 0.5class for 100-10000
4 Rated power supply: AC220v±10%,50Hz
5 Environment temperature:-5℃--40℃
6 Environment humidity :<85%
7 Size:430×320×215mm3
8 Weight:10kg
Shanghai TRIHOPE International Co., Ltdwas registered in Shanghai China in the year of 2003. Its total investment is about USD 2 Million. Being a professional foreign trading company, TRIHOPE is also the marketing institute of its sister company M/s SENERGE Electric Equipment Co., Ltd,which is a professional equipment manufacturer.
SENERGE Electric Equipment Company (SENERGE) was established in 2009, located in Shanghai Zhang Jiang Pinghu Hi-Tech Zone. The total investment of SENERGE is more than 5 million USD. SENERGE has full range of good machines and tools to ensure its machining process and offer customer good quality products.
Chen Jiabing (Chief Designer)
More than 35 years working experience of design and manufacturing in transformer industry. Served as tranformer and transformer equipment design and technology in Shanghai Transformer Factory, ALSTOM, AREVA, and other domestic transformer factories.
Wei Wang (Chief Production Officer)
With 35 years working experience in transformer industry. Served as transformer manufacturing in Shanghai Transformer Factory, ALSTOM, AREVA, and other domestic transformer factories.
Wang Daming ( Chief Service Officer)
Master degree of enigneering. 25 years working experience. Once worked in Pakistan, Indonesia overseas factories; visited nearly 40 countries, traveling throughout Africa, South America, America, Oceania, Asia and other places, with a wealth of experience working overseas.
