Test Voltage Stabilizer

Test Voltage Stabilizer thumbnail-1
Test Voltage Stabilizer photo-1
US$ 10.15 - 28.35 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
TTN
Usage:
Other
Contact Supplier Request Quote Chat Now
Zhejiang TTN Electric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name TTN
Usage Other
Phase Single Phase
Current Type AC

Specifications

It has the low energy consumption,the over voltage protection,the low voltage protection,the over-current protection,the over-lo

MODEL

PC-TZM500VA

PC- TZM 800VA

PC- TZM 1000VA

PC- TZM 1500VA

PC- TZM 2000VA

TECHNOLOGY

RELAY CONTROL SYSTERM+MICRO COMPUTER PROGRAMED CONTROL









LED DISPLAY

INFORMATION

INPUT VOLTAGE/OUTPUT VOLTAGE/LOAD USAGE/TIME DELAY/NORMAL WORKING/PROTECTION







PROTECTION

Over Voltage

Output Voltage≥243±4v

Low Voltage

Output Voltage≤188v±4v

Over Loading

More Than 120%

Over Temperture

120°C±10°C

Delay Time

Long time(255 seconds)/Short time(5 seconds)

Creepage



Language

English/Russia/Chinese

Input Voltage

AC150-270V(A TYPE);AC135-AC270V(B TYPE);AC105-AC270(C TYPE);AC80V-AC270V(DTYPE)

Output Voltage

220+/-10% adjustable

Frequency

50Hz/60Hz

Phase

Single phase

Efficency

≥90%

Ambient Temperature

-15°C-45°C

Relative humidity

<95%

Waveform distortion

No additional wave from distortion

Insulation resistance

Normally more than 2MΩ

Power

500VA

800VA

1000VA

1500VA

2000VA

Packing size(cm)

47.5*28.5*41.5

47.5*28.5*41.5

47.5*28.5*41.5

47.5*28.5*41.5

47.5*28.5*41.5

Packing (pcs)

6

6

6

6

6

G.M(KGS)

17.00

18.66

20.56

21.85

27.35

500
