Electromagnetic Flow Meter Made in China
Description
The magnetic flow meter is one of the most flexible and universally applicable flow measurement systems available
It is a volumetric flow meter which does not have any moving parts and is ideal for waste water applications or any dirty
liquid which is conductive or water based. Magnetic flow meter is also ideal for the applications where low pressure
drop and low maintenance are required.
Application
- Waster water industry: transport networks sewage treatment plants, sludges
- Chemical industry: acids alkalis, dosing applications, abrasive or corrosive mediums
- Metal & mining industry: mediums with a high solid content, like ore or excavator mud
- Water industry: Revenue metering, district metering water abstraction, leakage detection
- Pulp & paper industry: pulp, pastes, sludges & other caustic mediums, liquor, additives, bleaches, colourants
- Food & beverage industry: mixing, dosing and filling of drinks unde r hygienic conditions filling systems applications
Specification
Photo |
|
|
|
Converter |
Compact |
Remote |
Compact with Battery Power |
Accuracy |
0.5% of Rate |
0.5% of Rate |
1.0% of Rate |
Conductivity |
>5μs/cm |
>5μs/cm |
>5μs/cm |
Min. Velocity |
0.3 m/s |
0.3 m/s |
0.3 m/s |
Max. Velocity |
10 m/s |
10 m/s |
10 m/s |
Turndown Ration |
Standard 1:20; Others on request |
||
Output |
4-20mA/Pulse |
4-20mA/Pulse |
Consult the factory |
Power Supply |
(1) 110-240Vac |
(1) 110-240Vac |
Lithium Battery |
Communication |
Optional: RS485; MODBUS; HART; Profibus-DP |
||
Ex-Proof Level |
Exd[ia]qIICT5 |
||
Protection Level |
IP65 |
Converter: IP65 |
IP65 |
Diameter |
DN10-DN1200 |
||
Installation |
1. Flange (Standard: ISO; Optional: ANSI, DIN, JIS); |
||
Pressure Rating |
Standard: 1.6Mpa; Others on request |
||
Fluid Temperature |
Standard: PTFE: <120°C (customized PTF)E: <120°C) ; |
||
Ambient Temperature |
-30°C-60°C |
-30°C-60°C |
-30°C-60°C |
Weight & Packing
| Type | Flange | ||||||||||||||
| Diameter/mm | 6 | 10 | 15 | 20 | 40 | 50 | 80 | 100 | 150 | 200 | 250 | 300 | 400 | 500 | 600 |
| Net weight/KG | 6 | 8.5 | 9 | 9.5 | 10.5 | 13 | 16 | 18.5 | 31 | 40 | 60 | 75 | 120 | 180 | 300 |
| Packing | Carton Box | Wooden Box | |||||||||||||
Advantages Selling Points
- Accuracy:± 0.5of Rate / ±0.2% of Rate Ø OEM & ODM services
- Diameter range: DN4-DN3000 Ø Enough stock with short delivery time
- Fluid Temp.: - 20...+160°C Ø Quality product with competitive price
- Housing Material: Carbone steel /SS304 / SS316 Ø Fast response services
- Electrode material: SS316l /Titanium/ HC/Tantalum.. Ø Guarantee time is 24 months.
- Connection: wafer/ Sanitary / Flange Ø Certificate of CE & ISO 9001: 2008
Calibration Certificate
Model Selection
Packing & Shipping
Facility & Certificate
SURE Exhibition
Product Application
Product Gallery
How to Contact us
