10/100/1000Mbps 9 Port Managed Industrial Optical Fiber Switch
Overview
HiOSO FOWAY1509TFC-H includes managed and unmanaged types, is 9 ports 1000M security industrial Ethernet switch,with 8 ports 10/100/1000M adaptive RJ45 ports and 1 1000M Combo(1000M SFP port or 10/100/1000M adaptive RJ45 Ethernet optional) uplink port, supports SFP modules hot plug, and supports to work with fiber switches, fiber converters and other devices witch fiber ports, supports to choose Web and SNMP management, supports HD video flow transmission, applies to security system, electric system, traffic system requirements.
Character
Support maximum 8 ports 10/100/1000M adaptive RJ45 ports and 1 1000M Combo(1000M SFP port or 10/100/1000M adaptive RJ45 Ethernet optional) uplink port
Support SFP modules hot plug
Support 1000M port full rate, full duplex non-blocking forwarding
Support 8K MAC learning, 1Mbit storage and forward cache space
Each RJ45 port using anti-high voltage circuit, strengthen the lightning protection and anti-interference ability
Support to choose one side with fixed metal casing, external power design, better for heat dissipating and installation
Technical Specification
Parameter | Specification |
Standard | IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3ab 1000Base-T ,IEEE802.3z 1000Base-SX/LX Gigabit ethernet, IEEE802.3x Flow control, IEEE802.1q VLAN, IEEE802.1p QoS, IEEE802.1d Spanning Tree |
Wavelength | SFP module: 850nm/1310nm/1490nm/1550nm |
Distance | 1000M SFP module, Multi-mode: 220m(fiber 62.5/125μm)/550m (fiber 50/125μm) Single-mode: 10/20/40/60/80/100/120Km Single-fiber Single-mode: 10/20/40/60/80/100/120Km |
Port | 8 1000M RJ45 ports: 10/100/1000Mbps 1 1000M Combo ports: 1 Gbps,100M/1000M SFP&10/100/1000M RJ45 |
MAC address | 8K |
Buffer memory space | 1Mbit |
Bit error rate | <1/1000000000 |
MTBF | 100000 hours |
Power | DC12V/1A |
Power consumption | 7W |
Working temperature | -10~60℃ or -40~75℃ |
Storage temperature | -40~80℃ |
Humidity | 5%~90% non-condensing |
Dimension | 28mm (H)×193mm(W)×119mm (D) |
Order Information
NO | Type | Management | Ports | Working temperature |
1 | FOWAY1509TFC-H | NO | 8 1000M RJ45 ports +1 Gigabit Combo uplink (SFP fiber port /RJ45 Ethernet port optional) | -10~60℃ |
2 | FOWAY1509TFCM-H | YES | 8 1000M RJ45 ports +1 Gigabit Combo uplink (SFP fiber port /RJ45 Ethernet port optional) | -10~60℃ |
3 | FOWAY1509TFC-HT | NO | 8 1000M RJ45 ports +1 Gigabit Combo uplink (SFP fiber port /RJ45 Ethernet port optional) | -40~75℃ |
4 | FOWAY1509TFCM-HT | YES | 8 1000M RJ45 ports +1 Gigabit Combo uplink (SFP fiber port /RJ45 Ethernet port optional) | -40~75℃ |
Solutions
