IEEE802.3at POE Switch with 4 100M RJ45 PoE Ports 30W
Overview
HiOSO FOWAY2205P is five orts PoE Ethernet Switch, with four 100M RJ45 PoE ports and one 100M RJ45 or 000M fiber uplink port.
FOWAY2205P supports IEEE802.3af 15.4W and IEEE802.3at 30W PoE standards It can auto discovery the power receiving devices which support IEEE802.3af/at standard and supply power to it. To the connected devices which not support PoE, it will auto stop supplying power.
FOWAY1309PFC supports to work with IP camera, IP phone, wireless AP and other network devices, and supply power to these devices. FOWAY1309PFC supports web management and SNMP management; supports to transmit HD video flow; applies to Security system, electronic power system and traffic system requirements.
Character
l Support maximum 4 100M RJ45 PoE ports and 1 100M RJ45 or 1000M fiber uplink port
l Each PoE port supports to auto discovery the standard power receiving devices
l Support IEEE802.3af 15.4W and IEEE802.3at 30W PoE standards
l Support each 100M port full rate, full-duplex non-blocking forwarding
l Support 2K MAC learning, 1Mbit storage and forward cache space
l Each RJ45 port using anti-high voltage circuit, strengthen the lightning protection and anti-interference ability
l Support to choose one side with fixed metal casing, external power design, better for heat dissipating and installation
Technical Specification
Parameter |
Specification |
Standard |
IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3af, IEEE802.3at, IEEE802.1d Spanning Tree |
PoE |
PoE ports: 4 Standard and power consumption:IEEE802.3af 15.4W,IEEE802.3at 30W Working mode: auto discovery power receiving devices and auto power supply/power cutting |
Wavelength |
850nm/1310nm/1490nm/1550nm |
Distance |
multi-mode: 2Km Single-mode: 20/40/60/80/100/120Km Single-fiber single-mode: 20/40/60/80/100/120Km |
Port |
4 100M PoE ports: 10/100Mbps 1100M uplink port: fiber port : 100Mbps RJ45 port: 10/100M bps |
MAC |
2K |
Buffer memory space |
1Mbit |
Bit error rate |
<1/1000000000 |
MTBF |
100000 hours |
Power |
DC48V |
Power consumption |
4W, PoE power supplying maximum 120W |
|
Working temperature |
-10~60°C |
Storage temperature |
-40~80°C |
Humidity |
5%~90% non-condensing |
Dimension |
26mm (H)×140mm(W)×106mm (D) |
Order information
No |
Product code |
NMS |
Ports |
PoE ports |
1 |
FOWAY2205PF-4AF |
No |
4 100M RJ45+1 100M fiber uplink |
4 PoE ports IEEE802.3af 15.4W |
2 |
FOWAY2205PF-4AT |
No |
4 100M RJ45+1 100M fiber uplink |
4 PoE ports IEEE802.3at 30W |
3 |
FOWAY2205P-4AF |
No |
4 100M RJ45+1 100M RJ45 uplink |
4 PoE ports IEEE802.3af 15.4W |
4 |
FOWAY2205P-4AT |
No |
4 100M RJ45+1 100M RJ45 uplink |
4 PoE ports IEEE802.3at 30W |
5 |
FOWAY2205PFM-4AF |
Yes |
4 100M RJ45+1 100M fiber uplink |
4 PoE ports IEEE802.3af 15.4W |
5 |
FOWAY2205PFM-4AT |
Yes |
4 100M RJ45+1 100M fiber uplink |
4 PoE ports IEEE802.3at 30W |
7 |
FOWAY2205PM-4AF |
Yes |
4 100M RJ45+1 100M RJ45 uplink |
4 PoE ports IEEE802.3af 15.4W |
8 |
FOWAY2205PM-4AT |
Yes |
4 100M RJ45+1 100M RJ45 uplink |
4 PoE ports IEEE802.3at 30W |
