Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > OEM 1000M HD Video Fiber Media Converter for HD IP Camera

OEM 1000M HD Video Fiber Media Converter for HD IP Camera

Name: OEM 1000M HD Video Fiber Media Converter for HD IP Camera
Brand: Hioso
SKU: 117145785
Availability: InStock

OEM 1000M HD Video Fiber Media Converter for HD IP Camera thumbnail-1

OEM 1000M HD Video Fiber Media Converter for HD IP Camera photo-1

US$ 1 - 95 MOQ: 2 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Hioso

Model Number:

Foway 520AG, FC520AG

Contact Supplier Request Quote Chat Now

Hioso Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Hioso

Model Number Foway 520AG, FC520AG

OEM 1000M HD Video Fiber Media Converter for HD IP Camera

Overview
FC520AG is 1000M HD Video Fiber Media Converter, which is specially designed for Network HD IP camera and Network access control system. It supports long-distance stable HD Network video signals transmission through fiber cables. FC520AG can work with FTC-17 Media Converter rack in the central machine room.

FC520AG provides HD Network port, which can connect with HD IP camera or Network access control system.

Feature

Adopt special switch chipset design for HD Network video transmission;
Support 3.2G bandwidth high-speed storing, forwarding and access;
Support 1000Base-FX fiber transmission standard, compatible with other devices which supports 1000Base-FX standard;
- Support full-duplex and half duplex transmission modes and capable of automatic negotiation;
- Support VLAN tag long packets transmission;
- Support flow control, QOS and STP
- Support max distance 120KM transmission;
- FTC-17 Rack supports dual power supply redundancy backup and hot swap;
- Support 1M built-in high-speed cache capacity and 2K built-in MAC address buffer space
- Support lightning protection for electrical ports, low consumption and low heat, support long-term stable work.

Technical Specification

Parameter	Specifications
Access mode	10/100/1000Mbps
Standard	IEEE802.3 10Base-T Ethernet,IEEE802.3u,1000Base-TX/FX Fast Ethernet, IEEE802.3x Flow control,IEEE802.1q VLAN,IEEE802.1p QoS,IEEE802.1d Spanning Tree
Wavelength	850nm/1310nm/1550nm
Transmission distance	Dual-fiber multi-mode: 2Km; Dual-fiber single-mode: 25/40/60/80/100/120Km; Single-fiber single-mode: 25/40/60/80/100Km Category-5 twisted pair: 100m
Port	1 RJ45 port, connected to STP/UTP category-5 twisted pair 1 fiber port: Multi-mode - SC (fiber size: 50,62.5/125μm) Single mode - SC fiber port (fiber size: 9/125μm) Single-fiber single-mode - SC fiber port (fiber size: 9/125μm)
Conversion mode	Medium conversion, storing and forwarding mode
MAC address table	I K
Buffer space	1Mbit
Flow control	Full duplex state: flow control; half duplex state: back pressure mode
Delay	9.6us
Bit error rate	<1/1000000000
MTBF	100,000 hours
LED	POWER (power), FX LINK/ACT (fiber connection/action) FDX (FX full duplex mode), FX1000 (Fiber, with a transmission rate of 1000M) TP LINK/ACT (twisted pairs connection/action) TP1000 (twisted pairs, with a transmission rate of 1000M)
Power	DC5V
Power consumption	2W
Operating temperature	-10~55℃
Operating humidity	5%~90%
Storage temperature	-40~70℃
Storage humidity	5%~90% (non-condensing)
Dimensions	26mm(Height)96mm(Width)113mm(Depth) (external power) 77mm(Height)25mm(Width)110mm(Depth) (Module card)

Order Information

Model	Rate (Mbps)	Mode	Working Wavelength (nm)	Transmission Distance (Km))	Power
FC520AG-M2-SC	1000	Dual-fiber multi-mode	1310	2	External power
FC520AGC-M2-SC	1000	Dual-fiber multi-mode	1310	2	Module card
FC520AG-S10/20/40-SC	1000	Dual-fiber single-mode	1310	10/20/40	External power
FC520AGC-S10/20/40-SC	1000	Dual-fiber single-mode	1310	10/20/40	Module card
FC520AGS-S10/20/40-SC	1000	Single-fiber single-mode	1310	10/20/40	External power
FC520AGC-SS10/20/40-SC	1000	Single-fiber single-mode	1310	10/20/40	Module card
FC520AG-S60/80/100/120-SC	1000	Dual-fiber single-mode	1550	60/80/100/120	External power
FC520AGC-S60/80/100/120-SC	1000	Dual-fiber single-mode	1550	60/80/100/120	Module card
FC520AGS-S60/80/100/120-SC	1000	Single-fiber single-mode	1550	60/80/100/120	External power
FC520AGCS-S60/80/100/120-SC	1000	Single-fiber single-mode	1550	60/80/100/120	Module card
