2 Fiber Ports 3 RJ45 Ethernet Ports Ring Type 10/100Base Media Converter
FC650R 2 100M SC + 3 100M RJ45 Ring Type Fiber Media Converter
Overview
HiOSO FC650R series Ring type Media Converter is designed to meet requirements of multi fiber access network. It provides 2 100BASE-FX fiber ports and 3 10/100BASE-TX RJ45 ports, and one Console port, which provide not only point to point network connection, but also point to multi-point chain network. It has extend the transmission distance of a network from 100m over copper wires to 120Km (single-mode full duplex) and is applied to highway network system, mine communication system and other chain multi-point networks.
Features
l Provide two 10/100M fiber ports, three 10/100M RJ45 ports
l Support gigabit fiber Hiper-Ring network
l Support 128 ring network nodes
l Support redundant ring network protection (switching time<50ms, RSTP/STP
l Support WEB management, RSR (Rapid Super Ring)
l Working temperature is -10℃~70℃
l Supporting multiple types of fiber ports, such as dual-fiber multi-mode,dual-fiber single-mode and single-fiber single-mode, to satisfy the extended requirements of users
Technical Specifications:
Parameters |
Specifications |
Standard |
IEEE802.3 10Base-T Ethernet,IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.1d Spanning Tree |
Wavelength |
850nm/1310nm/1550nm |
Transmission distance |
Dual-fiber multi-mode: 220m(optical fiber size 62.5/125μm)/550m(optical fiber size 50/125μm) Dual-fiber single-mode: 10/20/40/60/80/100/120Km Single-fiber single-mode: 10/20/40/60/80Km Category-5 twisted pairs : 100m |
Port |
3 RJ45 port: Connected to STP/UTP category-5 twisted pairs 2 fiber port: Multi-mode – SC (fiber size: 50,62.5/125μm) Single-fiber single-mode – SC/FC fiber port (fiber size: 9/125μm) |
MAC table |
1K |
Buffer space |
512Kbit |
Delay |
<10us |
Bit error rate |
<1/1000000000 |
MTBF |
100,000 hours |
LED |
POWER(PWR),FX LINK1/2(fiber link/action),TP LINK1000 1/2/3(twisted pair link/action 1000M),TP LINK/ACT1/2/3 (twisted pair packet forwarding link/action) |
Power |
DC 12V |
Power consumption |
5W |
Operating temperature |
-10~70℃ |
Operating humidity |
5%~90% |
Storage temperature |
-40~80℃ |
Storage humidity |
5%~90% (non-condensing) |
Dimensions |
26mm(H)*96mm(W)*120mm(D)/ (height * width * depth) (external power) |
Order Information
Type |
Rate (Mbps) |
Mode |
Working Wavelength (nm) |
Transmission Distance (Km) |
Fiber Interface |
Power |
FC650RM-SC |
10/100 |
Dual-fiber multi-mode |
1310 |
2 |
SC/ST |
External DC12V |
FC650RS20/40/60-SC |
10/100 |
Dual-fiber single-mode |
1310 |
25/40/60 |
SC |
External DC12V |
FC650RS80/100/120-SC |
10/100 |
Dual-fiber single-mode |
1550 |
80/100/120 |
SC |
External DC12V |
FC650RSS20/40/60-SC |
10/100 |
Single-fiber single-mode |
1310/1550 |
25/40/60 |
SC |
External DC12V |
FC650RSS80/100-SC |
10/100 |
Single-fiber single-mode |
1310/1550 |
80/100 |
SC |
External DC12V |
