2 fiber ports 2 Ethernet ports Telecom Managed Media converter
Overview
HiOSO FC830ADC is an intelligent 10/100M adaptive fast Ethernet fiber converter (also called optical-to-electrical medium converter). It adopts two fiber ports two Ethernets port design, used as two independent fast Ethernet fiber media converters.
FC830ADC can be inserted into FTC-16M managed rack. The capacity of the rack extends from 16 converters to 32 converters, which save the space, lower the consumption.
FC830ADC can conduct mutual conversion between 10Base-T/100Base-TX twisted pair electrical signals and 100Base-FX optical signals. FC830A extends the transmission distance of a network from 100m over copper wires to 120 Km, and uses two network transmission technologies (that is, the data link layer 2 storing & forwarding mode and the physical layer 1 straight-through mode) to implement data transmission between the optical and electrical network connection mediums.
FC830ADC fiber converter supports transmission in dual-fiber multi-mode, dual-fiber single-mode and single-fiber single-mode fibers.
Feature
l 10/100 Mbps adaptive, for the convenience of network upgrade;
l Supporting full-duplex and half-duplex transmission modes and capable of automatic negotiation;
l Supporting automatic crossing of twisted pair ports, for the convenience of system debugging and installation;
l Supporting low-delay transmission;
l Supporting transmission of extra-long packets (with the maximum length of 1600 bytes);
l Supporting transmission of extra-long packets over VLAN;
l Supporting Quality of Service (QoS) and ensuring transmission of VoIP packets;
l Supporting Spanning Tree Protocol (STP) to form a redundant network;
l Extremely low power consumption (less than 2W), low heat and capable of stable operation for a long period time;
l Supporting multiple types of fiber ports such as dual-fiber multi-mode,dual-fiber single-mode and single-fiber single- mode, to satisfy the extended requirements of users.
l Application
10/100Mbps fast optical Ethernet long-distance transmission network
Technical Specifications
|
Specifications |
Access mode |
10/100Mbps |
Standard |
IEEE802.3 10Base-T Ethernet, IEEE802.3u, 100Base-TX/FX Fast Ethernet, IEEE802.3x Flow control, IEEE802.1q VLAN, IEEE802.1p QoS, IEEE802.1d Spanning Tree |
Wavelength |
850nm/1310nm/1550nm |
Transmission distance |
Dual-fiber multi-mode: 2Km; dual-fiber single-mode: 25/40/60/80/100/120Km;single-fiber single-mode: 25/40/60/80/100Km |
Port |
Two RJ45 ports: Connected to STP/UTP category-5 twisted pairs |
Conversion mode |
Medium conversion, storing and forwarding/straight-through |
MAC address table |
I K |
Buffer space |
1Mbit |
Flow control |
Full duplex state: flow control; half-duplex state: back pressure mode |
Delay |
Storing & forwarding: 9.6 μ s; straight-through: 0.9 μ s; |
Bit error rate |
<1/1000000000 |
MTBF |
100,000 hours |
LED |
PWR (power), FXL1 (fiber 1 port link/action) FXL2 (fiber 2 port link/action) |
Power |
DC5V 1A (card) |
Power consumption |
<2W |
Operating temperature |
-10~55°C |
Operating humidity |
5%~90% |
Storage temperature |
-40~70°C |
Storage humidity |
5%~90% (non-condensing) |
Dimensions |
110mm(H)*22mm(W)*81mm(D) /(height * width * depth) (module card) |
Order information
|
Rate (Mbps) |
Mode |
Working Wavelength |
Distance |
Fiber Interface |
Link |
Power |
FC830ADC-M2-SC/ST |
10/100 |
Dual-fiber multi-mode |
1310 |
2 |
SC/ST |
Support |
DC5V |
FC830ABC-M2-SC/ST |
10/100 |
Dual-fiber multi-mode |
1310 |
2 |
SC/ST |
Support |
DC5V |
|
FC830ADC- S20/40/60- SC/FC |
10/100 |
Dual-fiber single-mode |
1310 |
25/40/60 |
SC/FC |
Support |
DC5V |
|
FC830ADC- S80/100/120-SC/FC |
10/100 |
Dual-fiber single-mode |
1550 |
80/100/120 |
SC/FC |
Support |
DC5V |
FC830ABC- S20/40/60-SC/FC |
10/100 |
Dual-fiber single-mode |
1310 |
25/40/60 |
SC/FC |
Support |
DC5V |
FC830ADCS- S20/40/60/80/100-SC |
10/100 |
Single-fiber single-mode |
WDM 1310/1550 |
25/40/ 60/80/100 |
SC |
Support |
DC5V |
|
FC830ABCS- S20/40/60/80/100-SC |
10/100 |
Single-fiber single-mode |
WDM 1310/1550 |
25/40/ 60/80/100 |
SC |
Support |
DC5V |
