Profile
HA3202W is two-channel-100M outdoor equipment, with carrying capacity of 253 slaves per channel, total 506 slaves. It can work in atrocious weather with good stability because of its waterproof and lightproof shell.
Character
Supply 2 hybird signal output ports, each port can connect to maximum 253 users
Good anti-jamming capability with OFDM (kind of MCM, Multi-Carrier Modulation) and channel-adaptive technology
Highly adaptable to network, amplifier and distributor
Highly effective filter, lower interference to CATV
Supply VLAN, IGMP and QoS
Support SNMP, WEB and CLI management
Support remote software upgrade
Support integrated management for slaves
Support AC220V and AC60V power supply
Supply two data interfaces
Technical Specification
Parameter |
Specification |
System Bandwidth |
Physical layer data rate 200Mbps IP data throughput 100Mbps per channel |
Modulation |
OFDM BSPK, QPSK, 1024/256/64/16/8-QAM |
MAC Protocol |
TDMA and CSMA |
EOC technology |
HomePlug AV |
Frequency |
7.5 ~ 30MHz |
EOC module |
2 |
Carrying Capability |
253 per channel, total 506 slaves |
Protocol and Standard |
IEEE 802.1Q IGMP v1, v2 IEEE 802.1P QoS |
NMS |
WEB CLI SNMP |
Data Interface |
Two 10/100 Base-TX RJ45 input ports Auto MDI/MDIX Comply with 802.3 and IEEE802.3u |
TV Interface |
Two RF coaxial ports Metric thread F type Insertion Loss: <1dB Impedance: 75Ω |
Hybrid Interface |
Two RF hybrid output ports Metric thread F type Output level: 108dBμV Frequency: 2-870MHz Output Level: 108dBμV Impedance: 75Ω |
Light Indicator |
LINK (link LED) ETH (Ethernet port LED) Sys (system LED) PWR (power LED) |
Distance |
>700m |
Working Environment
Power |
AC220V/ AC60V |
Power Consumption |
7W |
Package |
310mm(length) × 220mm(width)× 120mm(height) |
Working Temperature |
-20°C ~ + 80°C |
Storage Temperature |
-25°C ~ + 85°C |
Operating Humidity |
20% ~ 85%(non-condensing) |
Storage Humidity |
10% ~ 90%(non-condensing) |
