Bank proximity reader time attendance highspeed flap barriers
Fujica Bank proximity reader time attendance highspeed flap barriers is designed to control pedestrian entering or exiting restricted areas, use SS304 stainless steel for the whole case, and adopt anti-damp, dust-proofing, water-proofing international standard design, suitable for both indoors and outdoors.
Flap barrier consists of cabinet,reader module,main control module,motor&driver module,infrared photocell,alarm device,limit switch and voice prompt device etc., can be used for the applications like apartment, factory, museum, station and ferry terminal etc.. Together with intelligent card reader/writer and management software, they are combined as intelligent flap barrier management system, can fulfill the functions like entrance control, time attendance, pedestrian volume control and tolling etc.
| Power consumption | 100W |
| Housing Size | 1400*280*950mm |
| Housing material | 1.5--2mm, 304# stainless steel, corosion resistant |
| Drive motor | DC brushless motor |
| Channel width | 500--600mm |
| Pass speed | 40 persons/min. |
| IP protection | IP44 |
| Input singal optional | DC12V/dry/contact/RS485/RS232/Remote) |
| railing-off against power off | Yes |
| Working enviroment temperature | minors 30°C to 70 °C |
| Working environments | indoor,outdoor |
| Relative humidity | ≤95% coagulation free |
| MCBF | 2,500,000 cycle |
Housing Size : 1400*280*950mm
- One year warranty
- OEM/ODM accept
- Free installation and maintanice trainning
- CE Certificated
- ISO passed
Established in Y2004, Fujica System Co., Ltd. is a professional developer and manufacturer of intelligentized access control systems.
After years of efforts in intelligent system applications, we have broken the traditional rules to achieve revolution in hi-tech intelligentized system applications by using new concept which turns technology into fashion life.
As one of the top-three companies in the industry, we have established our sales channel in more than 60 cities all over in China and are expanding our markets in overseas countries and regions.
We have totally 500 staff members, including a very strong R&D team with 50 engineers and technicians. They are always ready to meet your OEM/ODM requests. Backed by our experience and creativity, our products feature reliable performance and unique functions.
Making the best intelligentized products in China, FUJICA is adhering to the objective of "Leading at Home, Famous in the World".
