high quality embeded door access control

Specifications

1 32 digits ARM processor used
2 Simply system setting
3 Real time monitoring of each door status

standalone access control integarated access control



Fujica Access Control System is a sub-system of Fujica All-In-One system. It is built on an open and stable platform which can be run on Windows operation system and SQL server database platform. It is compatible for both single unit and network running to provide real time monitoring, controlling and managing your access control system.  SDK( Software Development Kit) is available for clients to develop its new software or to integrate into existing access control system.





Power/Current:	DC9V-18V/ Rated max. 500mA
Working temperature:	-30°C to 70 °C
Humidity:	≤95% coagulation free
Read/write time:	≤0.3S
Read/write distance:	3-5CM(IC)/5-10CM(EM)
Communication interface:	RS-485; TCP/IP
Storage capacity:	30,000pcs
Blacklist capacity:	50,000pcs
Storage capacity:	Record Storage:30,000pcs
Communication transmission distance:	1200m(RS-485) long distance communication network(optional)
Data saving time upon power off	≥10 years



32 digits ARM processor used
By using 32 digits ARM process, the system speed is highly improves

Simply system setting
All the settings can be done by software

Real time monitoring of each door status
By using management software, operators can monitor each door status in real time.

Compatible with both IC card and EM card



Multiple door open modes
Door can be open by reading card, manual button or software

Can set 3 door status and 8 time periods
8 time period can be set per day, we can set working status for any time period in one week.  There are totally three working status: keep open, keep close, normal.

Holiday setting function
Maximum 64 days can be set as holiday through software,

Available to work offline
Can read card and record card information offline for online data collection

Intimidation alarm available
When user is threatened to open door, user can use the intimidation card

Multiple alarm functions are available
Fire protection alarm, Break-in alarm, Intimidation alarm, anti-picklock alarm and open over time alrm. The alarm signal can be output by software setting, and alarming data can be uploaded to management center.

Multiple cards management mode
There are user card, intimidation card, security card, loss-reported card, recovered card etc. available
