Home > Instruments & Meters > Optical Lens & Instrument > Optical Lens > LSMO-8A Combined Multifunctional Grating Spectrometer
LSMO-8A Combined Multifunctional Grating Spectrometer
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangxi, China
Brand Name:
LSXPT
Model Number:
LSMO-8A, LSMO-8A
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Shanghai Tianjin Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Measuring Accuracy Laser Raman Spectrometer LSR-INegotiableMOQ: 1 Set -
BK7 Optical Plano Convex Lens LSA-0101NegotiableMOQ: 1 Set
-
100X 60X 40X 10X Biological Microscope ObjectivesNegotiableMOQ: 10 Pieces
-
Right Angle K9 Optical Quartz Prisms LSA-03NegotiableMOQ: 50 Pieces
-
Optical Polarizer Filter LSA-05 SeriesNegotiableMOQ: 10 Pieces
Place of Origin
Jiangxi, China
Brand Name
LSXPT
Model Number
LSMO-8A, LSMO-8A
LSMO-8A Combined multifunctional grating spectrometer
1.There are 2 collecting system(PMT and CCD) in LSMO-8/8A.
2.Using a large aperture grating as spectral component and fine grinding screw to make the test more accurately.
3.Configurate grating as your concrete requirment .
| Wavelength Range | 200nm-660nm(PMT) 300-900NM(CCD) |
| Focus | f=500mm |
| Optical Grating | 2400l/mm |
| Resolution Ratio | >0.06nm@2400l/mm |
| Wavelength Accuracy | 0.2NM |
| Slit | 0-2mm (adjustable or fixing) |
| Relative aperture | D/F=1/7 |
| Stray Light | ≤10-3 |
| Size | 560*380*230mm |
Note: Solidworks drawing available upon request.
