Help CenterPvc Ceiling Panel Production Line
Related Products
-
Pvc Panel Production LineUS$ 20,000 - 30,000MOQ: 1 Set -
Dryer MachineUS$ 3,500 - 5,000MOQ: 1 Set
-
Pvc Decorative Panel Production LineUS$ 21,000 - 26,000MOQ: 1 Set
-
Pvc Ceiling Panel Production LineUS$ 21,000 - 26,000MOQ: 1 Set
-
Jinzheng New Design Pvc Panel Machine/plastic Ceiling Making MachineNegotiableMOQ: 1 Set
Feature:
1.It is composed of conical twin screw extruder,vaccum calibration table,haul-off unit,cutter and stacker.
2.It is also coordinated with different break-section and mould to produce PVC door and window profiles,foamed special shaped materials,decoration plates,profiles and multi-hole wire plastic products etc.
3.The capacity of main extruder from 150kg/h to 450kg/h for option.
4. Special design for caterpillar type haul-off machine by particular up and down technology, working stable, reliable and heavy duty force
Length of vacuum calibration tank(m) |
4-6 |
Drawing speed(m/min) |
0-20 |
Double cutter power(kw) |
0.75 |
Maxpipe diameter(mm) |
16-63 |
Draw force(N) |
3000 |
Driving motor power (kw) |
3 |
PVC Panel Extruding Production Line- Main Technical Data
NO. |
Name |
Model |
Motor Power |
Production capacity |
Dimension(L×W×H) |
weight |
1 |
Extruder |
JZSZ—50 |
(20+15) kw |
100kg/h |
(3.5×1.3×2.3)m |
3.2T |
|
2 |
Panel forming table |
JZS—TY |
2.2kw |
sustainable work |
(1.3×0.8×1.6)m |
0.2T |
|
3 |
Traction Equipment |
JZS—TY |
2.2kw |
sustainable work |
(2.2×1.1×1.7)m |
0.8T |
4 |
Cutting Equipment |
JZS—TY |
Pneumatics |
sustainable work |
(0.75×0.72×1.3)m |
0.1T |
|
5 |
Shelf |
JZS—TY |
Pneumatic |
sustainable work |
(6.0×0.9×1.1)m |
0.03T |
