500LPH Tubular UHT

Name: 500LPH Tubular UHT
Brand: SUNSWELL
SKU: 117084837
Availability: InStock

US$ 30,000 - 32,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Place of Origin:

China

Brand Name:

SUNSWELL

Zhangjiagang Sunswell Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin China

Brand Name SUNSWELL

Model Number SSW-UHT-500L

Certification CE, SGS

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

A.Working conditions

Using purpose:used for the sterilization of Juice production
Effect of sterilization:commercial sterility
Capacity: 500L/h
Product: 100% natural juiceruspberry, blueberry and grape. is clear juice with no sugar and no pulp and no add water.
Sterilized temperature: 137℃

process flow:Inlet temp 25℃ warm-up 137℃sterilization holding 25 Sec cooling 87-93℃ filling
Design requirement:
- Full-automatic PLC control.
- Temp control of sterilization.

B.Technical description

1. Main equipment detailed list:

NO.	Equipment	Co.	State	Remark
1	THE type	Sunswell	China	SUS304, inner pipes: AISI 316L
2	Steam Pressure Reducing Valve	Spirax Sarco	England
3	Steam Regulation Valve	Spirax Sarco	England
4	Pneumatic valve	APV	England	Include all two-position-Butterfly Valve
5	Material Pump	Shanghai YUANAN	China
6	Hot water pump	DOOCH	Korea
7	Balance TANK	Sunswell	China	100L AISI 304 liquid level control
8	Hot water TANK	Sunswell	China	100L AISI 304
9	PLC control	Siemens	Germany
10	Touch screen	Siemens / Proface	Germany	color screen
11	Temp recorder	FUJI	Japan	color screen,register 3 temp&1 event
12	4S Holding tube	Sunswell	China
13	Temp sensor	Tempress	Denmark
14	electromagnetic valve	BURKERT	Germany
15	Digital paperless recorder	YOKOGAWA	Japan
16	Product flow meter	ABB	Germany
17	Flow meter for water	Weitai	China
18	Diaphragm pump	WILDEN	USA
19	Electric Components	Schneider	France
20	Frame Pipeline etc.	Sunswell	China
21	Standard tools,documents,spare parts	Sunswell	China
22	15 Sec Holding Tube	Sunswell	China
23.	CPM valve	APV	England

2. Power consumption data:for reference only

Base on 500L/h,temp parameter:5-70-137-87℃

type/pressure/temp	Power consumption
steam,0.6MPa(produce)	100Kg/h
steam,0.6MPa(pre-treatment)	100Kg/h
compressed air,≥0.6Mpa	100NL/min
electric power, three phase, 380V	approx 6KW
The precision of temp control	±1℃
maximum working pressure	1.6MPa
Equipment size	3000(L)×1500(B)×1700(H)
Equipment weight	1200Kg
