LP series bottle unscrambler is based on advanced foreign technology, according to requirements of beverage filling equipment high speed development, develop a domestic leading level bottle unscramble equipment.
a. Main characteristic
l Main motor reducer adopts torque limit institutions, to prevent failure damaged machine.
l Adopt hang bottle neck air conveyor, to prevent turnover when conveying.
l The bottle unscrambler has stuck bottles detector, if bottle stuck, it will stop automatically and alarm.
l The bottle unscrambler has no bottle detector, which used for sending work signal to the elevator, the elevator will supply bottle automatically.
l Air conveyor has photoelectric switch, which control the start-stop of bottle unscrambler.
l With maintenance door and mold changing door.
l The main electrical component (transducer, PLC, photoelectric switch, relay) use Mitsubishi, Omron, Siemens and other famous brands.
l Pneumatic circuit adopt international brand product.
b. Specification
l Touch screen: Weinview or Pro-face
l Inverter: Mitsubishi
l PLC: Mitsubishi
l Pneumatic cylinder: Festo
l Contactor & switch: Schneider or Siemens
l Photoelectrical switch: Autonics
l Motor: Boneng
c. Technical parameter
Unscrambler
l Model: LP-24
l Number of working positions: 24
l Capacity: 24,000BPH (500ml)
l Pressure of air supply: 0.7MPa
l Air consumption: 2M3/ min
l Applicable bottles: diameter of 50-96mm, height of 165-310mm
l Power of main motor: 4KW
l Dimension: Φ3400×2650 (dia.×H)
l Machine weight: 5000Kg
Elevator
l Model: TP6
l Power of motor: 1.1KW
l Dimension: 6800×800×3400 (L×W×H)
