Home > Products > 12.Press Bagging Machine Series > Compressed Packing Machine

Compressed Packing Machine

FOB Price

Negotiable / Set

20 Sets(Min. Order)

Port Shanghai
Payment TermsMoney Gram

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Other, bagasse compressor
Packaging Type	Cartons	Packaging Material	Wood
Automatic Grade	Automatic	Driven Type	Hydraulic
Voltage	3PHASE	Power	18.5KW
Place of Origin	Shanghai, China	Brand Name	JEWEL
Model Number	JPW-KT140	Weight	3000kg
Dimension(LWH)	392028801700mm	Certification	CE, ISO, TUV, SGS
After-sales Service Provided	Engineers available to service machinery overseas

Packaging Details

bagasse compressor, by wooden case

Product Description

Specifications

bagasse compressor
PLC automatic operation
bagasse packing machine
feed by belt conveyor
CE, ISO, TUV

bagasse compressor

bagasee compressor uses PLC control system, hydraulic transmission, horizontal level bagging, out bag with high speed and high yield.
The operation is simple, easy to used and high degree of automation, using artificial feeding or automatic feeding conveyor.
The bagasse compressor is suitable for Ground Nut Shells, wood shaving, forage, leaf, wood chips, silage, rice husk, fiber, sawdust, the cotton seed shell, peanut shells husk etc material compression, pression and bagging by one time, convenience for store and reduce the transportation cost.
After compressed, easy to remove loose,bagasse compressor can be used in environmental building materials,farmland fertilizer, such as mushroom cultivation and so on.

Parameter

Model	JPW-KT90		JPW-KT110	JPW-KT140	JPW-KT180
Hydraulic power	40/50Ton		50/60Ton	60/80Ton	80/100Ton
Packaging size(*LWH*)	*750430310mm*		*750430310mm*	*750430310mm*	*750430310mm*
Feed opening size(*LH**)	*1000700mm**		*1000700mm**	*1000700mm**	*1200700mm**
Packing materials	Hay/ mineral wool/ cotton seed/ corn cob/ saw dust/ wood shavings/ rice husk/ saw dust/ wood shavings/ rice husk
Capability	1.5-1.8T/hour	2-2.5T/hour		2.5-3T/hour	3-3.2T/hour
Capability	50—60 bales / hour
Voltage(can be customized)	380V/50Hz		380V/50Hz	380V/50Hz	380V/50Hz
Power	11KW/15HP		15KW/20HP	18.5KW/25HP	22KW/30HP
Machine size(*LWH*)mm	*392028801700*		*392028801700*	*392028801700*	*425031001700*
Weight	2400Kg		2700Kg	3000Kg	4300Kg
Bag size	*7601150mm**

Appearance

Competitive Advantages

Got CE, TUV, SGS and IS0 9001:2008 certificates
Elaborately chosen components with best quality
18 years mature established company
More than 70% of products for export, supply golden quality
Having built business relationships with more than 90 countries, with good credibility and reputation

Contact person: Julie Ku

Cell: 0086-1391806182

Skype: jiajing812

Company Profile

Shanghai Jiajing Machinery Co., Ltd.

Shanghai Jiajing Machinery Co., Ltd. specializes in the designing, manufacturing and distribution of packaging machines, packaging materials and hydraulic machines. We have excellent engineers and technicians in R&D department. We have factories in Shanghai City and Nantong City. These factories can manufacture more than thousands sets of hydraulic machines. With adopted modem management experience and the advantages of technique, some products of our company have been exported to Japan, Europe and America. We can provide high quality and professional services to our customers. Our environmentally friendly machines can make live the garbage, industry garbage, and attain the classification with compress to handle, protect the living environment, and reduce the conveyance cost. They are societies to develop, and the business enterprise reduces conveyance with warehouse space of essential equipment. Now current supply is short of demand in Euro-American markets, so these products have great development space. The price of my company has strong competition ability in abroad markets. We sincerely welcome all clients to contact us.
