chemical application filling machines
This model is designed mainly for the fine powder which easily to spout dust and high-accuracy packing requirement.
Based on the feedback sign given by below weight sensor, this machine do measuring, two-filling , and up-down work ,etc.
It is specially suitable for filling additives, carbon powder, dry powder of fire extinguisher, and other
fine powder which needs high packing accuracy
1. Lathing auger screw to guarantee the precise filling accuracy
2. PLC control and touch screen display
3. Servo motor drives screw to guarantee stable performance
4. Quick disconnecting hopper could be washed easily without tools
5. Can be setting to semi-auto filling by pedal switch or auto filling
6. Full stainless steel 304 materia
7. Weight feedback and proportion track to materials, which overcomes difficulties of filling weight changes due to materials’ density change.
8. Save 10 sets of formula inside the machine for later use.
9. Replacing the auger parts, different products ranging from fine powder to granule and different weight can be packe
10. Weight sensor is below the tray, to do fast filling and slow filling based on the pre-set weight, to guarantee the high packaging accuracy.
Model |
TP-PF-B12 |
Control system |
PLC & Touch Screen |
Hopper |
Quick disconnecting hopper 100L |
Packing Weight |
1kg – 50kg |
Dosing mode |
With online weighing; Fast and slow filling |
Packing Accuracy |
1 – 20kg, ≤±0.1-0.2%, >20kg, ≤±0.05-0.1% |
Filling Speed |
2– 25 times per min |
Power Supply |
3P AC208-415V 50/60Hz |
Total Power |
3.2 KW |
Total Weight |
500kg |
Overall Dimensions |
1130×950×2800mm |
2. powder mixing machine
3. Continous Bag Sealing Machine
Automatic Bottle Spice Packing Machine Price - Buy Powder Filler,Spice Packing Machine Price,Automatic Packing Machine Product on
|
Main machine: 1. Tightly fixed in plywood case 2. Dust-proof plastic film 3. Packing size: 1240*1100*2500mm 4. Pack weight: 350 kg |
Spare parts: 1. One set of maintenance tool 2. English manual 3. Quality certificate 4. Packing list |
