10.1'' FPV monitor built-in battery dual 32CH 5.8GHz diversity receivers high resolution 1024x600 dji gimbal

10.1'' FPV monitor built-in battery dual 32CH 5.8GHz diversity receivers high resolution 1024x600 dji gimbal

This FPV monitor is a medium sized 10.1" screen with a super bright LCD and 5.8GHz 32CH diversity receiver,  built in rechargeable battery. Excellent choice for your FPV monitor, or as a secondary backup screen for your friends to watch. The 500cd/m² is plenty bright for outdoor applications where you need a bright screen, and the included sun shade will help keep unwanted light off the screen, reducing glare. The integrated rechargeagble battery keeps your FPV grounstation compact and easy to use.Perfect for outdoor operation.

This monitor will not go to a blue or black screen when video signal is lost or static. Perfect for an FPV application where you don't want your screen to go blank when the video signal is weak.

1. Built-in integrated lipo battery
2. Channel Auto searching ,selection via button
3. Best Channel Receiption via Antenna Auto-switching
4. 5.8GHz,32 Channels Receiver
5. Video outputs and DC output to connect and power other equipment
6. High resolution 800x480,Bright 450cd/m²
7. No blue screen
8. High Sensitivity:-90dBM
9. Compable with all 5.8GHz transmitters 32ch, such as Fatshark, Boscam
10. Not affected by 2.4ghz radio controller

 Photography Functions:

*Peaking Focus Assist
*Check Field(Red,Green,Blue,Mono)
*Camera 5D II Mode
*Screen Marker
*Centre Marker
*4:3&16:9 image adjustable
*Full Screen Display in mode of Monitoring&Recording

 Multiple Inputs and Outputs

 HDMI,Audio,Video,RF input,3.5mm Earphone Jack output.and with USB for upgrade

Channel Auto Scan

It supports 32-channels totally, Long press “Search” button to realize auto channel searching function when aerial photography. It’s much more convenient than traditional methods.

 5.8GHz Wireless AV Receiver

.Built-in AV receiver support PAL / NTSC
.Simulation of composite video AV inputs, aerial camera connection.
.5.8Ghz frequency 4 Bands and total 32 channels.
.Snow screen, no more “blue” screen.
