GW-2030MT 1 color 1 station desktop vacuum table screen printing press
Widely application:
It is suitable for printing different material flat items such as paper/textile bag,mosue pad,glass,aluminum/metal board,PCB circuit board,plastic film,pp/pet/pc/pvc sheet,warning sign,keyboard,ceramic tile,leather bag,medical box,aluminum box,wooden board,arylic board,carton sheet.....and so on
1, This flat screen lifting method allows the operator to easily load and unload small injection molded parts such as; cigarette lighters, ice scrapers, flying discs (aka Frisbee™), first aid kit boxes, display boxes, CD's & DVD's and much more.
2, Suit for industrial goods such as; circular saw blades, stamped steel panels, chassies, and various automotive components. The horizontal printing axis is controlled pneumatically by a rodless cylinder and is quickly adjustable with quick release stop guides.
Tech-data:
Max. Frame size |
300x550 mm |
Worktable size |
250x450mm |
Max. printing area flat |
200*300mm |
Max. workpiece height |
150 mm |
Vacuum size: |
180*280mm |
Printing stroke(left and right) |
350mm |
Screen lift stroke(up and down) |
160mm |
Max. printing capacity |
up to 1200pcs/hour |
Air pressure |
5-7 bar |
Dimension |
770*870*980mm |
Net Weight |
140 Kgs |
Voltage |
220V |
Printing head: |
pneumatic cylinder control |
Feature:
1. SCM IC coordinate light touching panel to complile action programming
2. Auto 4-digit counter built-in, counting printing quantity
3. Airframe adopts coin alloy,and metal coating surface
4. Distyle vertical constructure, high precision, steady operation
5. The transeversa stroke can be adjusted, spacing by Taiwan electronic switch
6. The angle of scraper and ink covering blades can be adjusted randomly
7. Installing scraper constant pressure equipment to make sure pressure is steady when printing
8. You can regulate work-table back and forth or right and left, and then fastening it
9. You can regulate screen frame back and forth, right and left or level orientatio
10. Vacuum stainless steel worktable, it can absorb kinds of film products
11. Installing CEC oil buffer on up and down, left and righ to avoid printing shock
12. The machine is running fastly, steably and lower noise.
13. Action model option: fully automatic | semi-automatic | manual
14. Start-up method:panel | foot switche
Advantages:
• Electro-pneumatic controlled
• Pneumatic controlled with shock absorbers
• Vertical head lift with height adjustment
• X/Y/R positioning table with or without vacuum table
• Linear ball bearings on hardened shafts
• Squeegee angle and calibrated height adjustment
• 250 x 450mm (9.45" x15.75" ) vacuum work table,low noise and fix products better
• Regulated squeegee pressure with pressure gauge
• Table top machine with adjustable levelers
• Foot switch controlled
Remark:
| Machine Warranty: | Any questions within 1 year without human damage,we can send any parts of machine to you freely |
| Payment term: | T/T,Western Union,Paypal |
| Mini order quantity: | 1 set |
| Leading time: | We can finish it within 3-7 workdays after get your payment |
| Delivery way: | It can according customers's requirement to choose by sea or by air,by expresss |
| Price termn: | EXW,FOB,CIF,CFR,C&F..etc |
Machine picture:
