Single Machine Core Control Board Automatic Swing Gate
Specifications:
Technical Data |
DB305-H |
Passage width |
≤ 960mm |
Throughput rate |
35p/m |
Power supply |
100~240v |
Operational voltage |
24v |
Max power consumption |
50w |
Frequency |
50~60hz |
Prectection level |
44ip |
Working temperature |
-25~70°C |
Electro-magnetic drive |
DC |
Dimension excluding bars |
1400x280x980mm |
Net weight including bars |
170kg |
Competitive Advantage:
1.1.5mm thickness 304 stainless steel
2. RFID card (IC/ID), Barcode, fingerprint, control accepted
3. CE and ISO 9001-2008 certified
4. OEM and ODM are welcome.
Description:
1. Unique incomplete wheel transmission is adopted to make turnstiles held or unheld in zero position more accurate and
reliable.
2. Running stable, little noise and no mechanical impact
3. Self-checking-power-on function, if power on, turnstile will auto get to be held.
4. Various working means can be set in the control panel menu, 5. If power off, arm will fall automatically while power on later,
arm should be lift by hand. First press the arm with a little force and then lift it manually.
5. RS485 connection for far control arm up and down to satisfy the special needs or fire control requirements.
7. It is with standard electrical interface to connect various kinds of readers and writers for easy integration and alsocomputer far control and management can be realized by computer.
8. It will count the pedestrian and will show the number on LED display directly. (LED is optional)
9. LED direction guide
10. Card reading memory or card reading without memory function can be set.
11. If working with software, the total-in-population can be set to satisfy special request.
12. Re-position function.
13. Card mounting is available.
14. Uncompleted wheel turning system is adopted for locking the turnstile in zero, and unlocking will be more reliable and accurate.
15. Extend:
1), Voice prompt
2), dual color, 4 words LED display
3), fingerprint card
4), spit vote
5), remote mode
16, Audio prompt function is optional.
17, Effective railing barrier opening signal with memory and without memory can be set (adjustable).
Packing:
Shipping ways:
Payment terms:
1. western union
2. T/T
3. Paypal
Return and Warranty:
Our company products are guaranteed for one year, from date of sale providing free maintenance based on not being damaged by any man-made.
♦ During the warranty period, all faults caused by the product itself can be maintained for free.
Please carry the filled warranty card and the purchase invoice to the authorized service centers across the country or retun the machine to our company for freerepair.
♦ Within the period of free maintenance, faults or damages caused by mane-made or natural disasters can be maintained with additional charge.
♦ Over the period of free maintenance, faults or damages can be maintained with additional charge.
The following conditions are not under warranty:
♦ Damages caused by abnormal operation, man-made or naturaldisasters;
Note: The warranty card and purchase invoice are used as warranty certificates to maintain the machine. Please reserve them carefully.
Project Case:
♦ Bus station (Vietnam) ♦ Factory (Indonesia)
♦ Company (Thailand) ♦ Colledge (England)
♦ Factory (Philippines) ♦ District (Malaysia)
Why choose RHT as your ideal suppliers?
ShenZhen Ruihongtai Security Technology Co., Ltd is located in ShenZhen city, has full experience in the EAS/Turnstile industry, with a strong technical team, followed by the international leading technology, be able to provide customers with best quality products and good service.Our Products have been widely used in the Middle East,Southeast Asia,Europe,North Africa and other countries and regions.We have passed the CE,RoHS and other certification.We have a professional installation team,so we can help to supply the installation instructions.
1.Are you a factory or trading company?
A:We are a RF&AM EAS System and Turnstile factory.and we are manufacturer with more than 20 years in EAS field.customized products is allowed.
2.How to testing the Turnstile Barrier Gate?
♦ Check the wiring
When connected power debugging, please check the wiring diagram according to each parts of the line is connected.
Note: protective earth wire of equipment must reliable grounding,otherwise don't allow debugging.
♦ Function test
◊ Turnstile actually pick two way signal (come in and out ).
◊ If the installation has LED indicator light on the surface, if the control PCB board receive the legitimate signal, turnstile will have green arrows in the direction.
3.What's your Advantages?
♦ Laser cutting ♦ Digital punch machine (control press)
♦ Digital grooving♦ Digital bending machine(press brake)
