Product Details
Place of Origin: | Henan, China | Brand Name: | Anjit | Model Number: | PP |
Product Description
plastic formwork for concrete (PP)
PP formwork for concrete wall, column, roof , beam
Name | Size (Width*Length) |
Formwork (Cast wall, roof, beam, and column on site) Weight: 12kg/m2 Thickness: 55mm | 900*1800mm |
900*1800Cmm | |
900*1500Cmm | |
600*1800Cmm | |
600*900Cmm | |
900*1800mm | |
900*1500mm | |
600*1800mm | |
600*900Cmm | |
450*1800Cmm | |
500*1800Cmm | |
400*1500mm | |
400*1500Cmm | |
300*1500Cmm | |
300*900Cmm | |
300*600mm | |
250*900mm | |
250*600mm | |
250*300mm | |
200*900mm | |
200*600mm | |
200*300mm | |
150*900mm | |
150*600mm | |
150*300mm | |
130*900mm | |
120*900mm | |
100*900mm | |
Male corner connection formwork Weight: 0.65kg
| 55*55*900mm |
Female corner formwork Weight: 1.468kg
| 150*150*450mm Weight: 1.468kg |
Buckle Weight: 0.1kg
| It asks 12pcs of buckles for 1m2 wall |
Shipment:
We offer installation service as per customers requirements and needs;
Clients can also study technology in our factory freely.
Formwork
Thickness: 55mm
Specification:
900*1800*55mm, 900*1800C*55mm,900*1500C*55mm,
600*1800*55mm, 600*1800C*55mm,600*900C*55mm,
500*1800C*55mm,
450*1800*55mm,
400*1500*55mm, 400*1500C*55mm,
300*1500C*55mm, 300*900C*55mm,300*600*55mm,
250*900*55mm, 250*600*55mm, 250*300*55mm,
200*900*55mm, 200*600*55mm, 200*300*55mm,
150*900*55mm, 150*600*55mm, 150*300*55mm,
130*900*55mm,
120*900*55mm,
100*900*55mm.
Plastic concrete formwork (PVC)
Specification:
width 915mm or 1220mm,
length no limited,
thickness 12~18mm
Common size used in construction: 915*1830*15mm or 1220*2440*15mm
Performance:
1- Level and smooth surface:
2- Light weight and easy for assembling;
3- Easy demould, no need brush parting agent;
4- Stability and weather proof: during -20degree and 60degree, no shrinkage, no swelling, no cracking, no deformation, Alkali-resistance, corrosion protection, fireproof, waterproof, heat resistance, electric insulation;
5- Good variability: the shape and the specification could be changed according to the construction situation.
6- Low cost: recyclable, longlife span;
7- Energy conservation and environment-friendly etc.
Pictures:
Install instruction:
1- Easy to nail, drill, and cut and size you want;
2- 150mm between the battens or supporters;
3- 400mm between the Strengthen screws(Dia. 12mm);
4- 400mm between the cross bars;
5- When demould, don't be violent.
