Home > Products > Vibrating screen > 2014 best selling gold rotary trommel screen/grizzly screen for mining
2014 best selling gold rotary trommel screen/grizzly screen for mining
- 100 Unit / Units per Month
- Qingdao Shanghai
- T/T
Product Details
| Condition: | New | Type: | Circular | Application: | Ore |
| Place of Origin: | Henan, China | Brand Name: | DONXE | Model Number: | GT1015 |
| Voltage: | 220V | Power(W): | 3 | Dimension(L*W*H): | 2600*1400*1700 |
| Weight: | 0.87t | Certification: | CE, ISO9001 | Warranty: | 1 year |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
grizzly screen for miningSimple structure, smooth running, low noise, less blocking of mesh screen.
grizzly screen for mining consists of hopper, screening drum, frame, motor and reducer. It is configured for material classification, screening, grading
1. Input of raw materials through heavy equipment
Raw materials inputted through the entrance of the hopper will be pushed into the trommel screen by the strong water pressure of the shower equipped in the HOPPER.
2. Selection and cleaning of raw materials
Raw materials of the trommel screen will be cleaned and selected by the rotation of trommel screen and, by watering of the shower inside, run into the gold dust separate panel.
3. Collecting of gold dust separated
Soil and sands with lighter specific gravity will flow away but gold dusts with greater specific gravity will be staying in the gathering mat to be collected.
Basic Information of Rotary Drum Screen
1. Functions: configured for classification, screening, grading
2. Type: open type, closed type
3. Classification: shaft rotary screen, shaftless rotary screen
4. Construction: carbon steel, stainless steel
5.Applications Scope: widely used in chemical, coal, construction, gold mine, plastic, quarry, recycling, metallurgy, mineral-selecting industries, etc.
Model | Capacity (t/h) | Drum Diameter (mm) | Drum Length (mm) | Granularity(mm) | Power (kw) | Dimensions(mm) | |
Feeding | Discharging | ||||||
GT1015 | 50 | Ø1000 | 1500 | ≤300 | 0-100 | 3 | 2600*1400*1700 |
GT1020 | 100 | Ø1000 | 2000 | 4 | 3390*1400*2140 | ||
GT1225 | 160 | Ø1200 | 2500 | 5.5 | 4146*1600*2680 | ||
GT1530 | 250 | Ø1500 | 3000 | 7.5 | 4460*1900*2820 | ||
GT1545 | 350 | Ø1500 | 4500 | ≤400 | 11 | 5960*1900*3080 | |
GT1848 | 450 | Ø1800 | 4800 | 15 | 6500*2350*4000 | ||
GT2055 | 600 | Ø2000 | 5500 | 22 | 7500*2500*4800 | ||
GT2265 | 800 | Ø2200 | 6500 | 30 | 8500*2750*5000 | ||
1. Large processing capacity
2. Simple structure, smooth running, low noise
3. Easy installation and maintenance
Our company is a large industrial machinery manufacturers in China and focus on mining machinery, complete sets of processing equipment, building materials equipment of rotary kiln. Our company has the quite rich experience and solid strength in the independent design and manufacture complete sets of crusher, beneficiation equipment, rotary kiln, making sand production line, stone production line, sand production line and complete set of equipment of cement production line, etc. And it has through the strict international quality system certification. The high-tech content, high reliability, low maintenance cost make our products has been at the industry-leading level. At present, our factory has been exported to more than 10 countries, used in mining and construction widely.
