Large Round Parts Pit/Well Type Heat Treatment Furnace
This well type annular parts heat treatment furnace is specially aimed at annular flange parts producers with max furnace diameter at 8.5m. The furnace is comprised of furnace body, furnace cap and control system.
Structure introduction
The furnace body is a weldment of sectional steel and steel plates.
The furnace body is specially designed with chrome-manganese-nitrogen mouth ring to protect the heat preservation cotton from damage by the workpieces and thus keep the furnace temperature uniformity. The heating components are the high-resistance OC25AL5 heating belts. The furnace body is lined with high-pure silicate aluminum fiber cotton blocks. The inside wall is suspended with heating components.
The furnace bottom is weight-bearing, and therefore is laid with high-aluminum refractory bricks. The furnace bottom is also covered with chrome-manganese-nitrogen sizing blocks to increase the temperature uniformity.
The furnace cap is lifted by the hydraulic mechanism. recording: colored LED non-paper recorder to record the process curve.
Temperature control: 10-segment control
Control system :
PID control
Double protection by contactor and SCR. K-type porcelain thermal coupling;
The furnace is nude packed but duly fixed inside the container.
The nearest sea port is Shanghai port which is the largest and most convenient port over China.
The delivery time is 45-120 days after receipt of down payment.
The furnace is usually loaded into normal containers (20GP or 40GP) or flat racks.
Our company provides test-running service to the customers. We would send our engineers to the buyer's site for installation, test-running and training service. The customer should bear the following costs: round-way air ticket fare, and board and lodging, and daily allowance.
The warranty period is 1 year after completion of test-running.
We provide technical support life-time.
Wuxi Wondery Trading Co., Ltd is a comprehensive furnace supplier. We can supply the following products: box type furnace, bogie hearth furnace, hot air circulation oven, well type furnace, hood type furnace, tube type furnace, mesh belt furnace, continuous type roller type, continuous roller hearth furnace, tilting roller furnace, push rod furnace, steel strip furnace, aluminum alloy quenching furnace, aging furnace, brazing furnace, laboratory furnace, crucible furnace, and aluminum melting and holding furnace. The heat treatment furnace treats the workpieces under protective atmosphere, control atmosphere, or vacuum status and with energy mediums such as electricity, natural gas, coal gas, industrial fuel oil and others.
1) Q: What is the power supply of the equipment?
A: The power supply of the machine is to be decided by the customer's side. We are able to adjust the voltage (volt, and phase) through a transformer so that the machine is ready for use at the end user's site.
2) Q: What information should the customer provide to get an accurate quotation from us?
A: The customer should provide the working temperature, temperature rising speed, energy medium (gas or electricity), effective size of the furnace, drawings, pictures, industrial voltage, etc.
3) Q: What is the payment term?
A: The payment term is 30% down payment, and 70% before delivery (T/T mode).
4) Q: What is the delivery time?
A: The delivery time of the machine is 45-150days after receipt of down payment.
5) Q: What is the warranty period of the machine?
A: The warranty period is 1 year after completion of test-running.
6) Q: How to contact us?
A: Contact person: Ms Ruth from Sales Department
Website: /
Mobile: +86 1530 5299 442
Skype Id: wonderymc
QQ account: 1292627586
