Specifications
topkit tower crane 50131.With Hydraulic Self-raising Mechanism,
2.Variable-frequency Slewing Mechanism,
Beijing Jiuhong Heavy Industry Machinery Co., Ltd , a leading manufacturer of construction machinery for 14 years Construction elevator, Suspended platforn ,Material hoist, Consrete spreader are our major products .
To provided satisfied productions and serices is our eternal pursuit and promise . Beijing Jiuhong Heavy Industry hopes to cooperate with you sincerely.
Construction Building Tower Crane
Technical Parameters
Model |
QTZ63B(5610) |
QTZ63B(5013) |
Jib Length (M) |
56 |
50 |
Free Height (M) |
41 |
41 |
Max. Possible Height (M) |
161 |
161 |
Max. Load (T) |
6 |
6 |
Tip Load (T) |
1.0 |
1.3 |
Wall-attached Device for Max Height (sets) |
6 |
6 |
Main Material (mm) |
Standard Mast Section 135×135×10 (Square Steel Tube) |
Standard Mast Section 135×135×10 (Square Steel Tube) |
Mast Section Dimension (m) |
1.835×1.835 ×2.5 |
1.835×1.835 ×2.5 |
Hoisting Speed (a=2) (m/min) |
80/40/10 |
80/40/10 |
Min. Stable Falling Speed (m/min) |
5 |
5 |
Slewing Speed (r/min) |
0-0.62 |
0-0.62 |
Radius-changing Speed (m/min) |
40/20 |
40/20 |
Jacking-up Speed (m/min) |
0.6 |
0.6 |
Total Motor Power (kw) |
55.2 |
55.2 |
Power Supply |
380V/50HZ |
380V/50HZ |
Weight of Independent Structure (T) |
36.80 |
36.80 |
Counterweight (T) |
14.85 |
14.85 |
Base Form |
Embedded Type (Outrigger Stationary) |
Embedded Type (Outrigger Stationary) |
Number of Containers Needed for Shipment (Free Height) |
6 * 40HC containers |
6 * 40HC containers |
Main Technical Parameters
1) Nominal Lifting Moment: 800KN.m
2) Working Range: 3-56m
3) Max. Lifting Capacity: 180t
4) Independent Standing Height: 45m
5) Attached Standard Height: 180m
6) Lifting Speed: 0-80m/mim
7) Slewing Speed: 0-0.7r/min
8) Radius Changing Speed: 0-47.3m/mim
|
|
||||||||||||||||||||||||||
Beijing Jiuhong Heavy Industry hopes to cooperate with you free to contact:
