provide customized pipe fittings mold

Mould Material

S50C, P20,718H,etc.

Mould Base

LKM,HASCO or else

Hot Runner

HASCO,YUDO,DME etc.

Standard Component

DME,HASCO,JIS etc.

Mould Life

300,000 to 1,000,000 shot

Design Software

UG,PRO-E,AUTO-CAD

Process Machine

CNC, EDM, Wire Cut, Flying cutter, Drill.

1.Quote

According to sample, drawing and specific requirement.

          ↓

2.Discussion

Mold material, cavity number, price, runner, payment, etc.

          ↓

3.S/C Signature

Approval for all the items

↓

4. Advance

Pay 50% by T/T

          ↓

5.Product Design Checking

We check the product design. If some position is not perfect, or can not be done on the mould, we will send customer the report.

          ↓

5.Mould Design

We make mould design on the basis of confirmed product design, and send to customer for confirmation.

          ↓

6.Mold Tooling

We start to make mold after mold design confirmed

          ↓

7.Mold Processing

Send report to customer once each week

          ↓

8.Mold Testing

Send trial samples and try-out report to customer for confirmation

          ↓

9. Mold Modification

According to customer’s feedback

↓

10.Balance settlement

50% by T/T after the customer approved the trial sample and mould quality.

↓

11.Delivery

Delivery by sea or air. The forwarder can be designated by your side.

Major Equipments

Numbers

CNC

10sets

EDM

6sets

Wire-cutting

8sets

Drilling Machine

3sets
