Aerated water filling line/beer bottling line
1). Our company beer machines are Compact structured, good-looking, easy to operate and highly automated. PET bottled and glass bottle beer filling machine with capacity from 2000BPH to 20000BPH.
2). Conveyor is directly linked with feed-in starwheels, making it easier to change bottles without screws and conveyor chains.
3). Bottles are transferred in the manner of clamping neck. Bottles can be changed through some replacement of steel clamps, which instead of adjusting the height of machine.
4). Rinser-clamp which special design is strong and endurable, no contact with bottle-mouth, to prevent pollution. Highly effective spraying nozzles equipped on the rinser-clamp can rinse every side of inner bottle and save water.
5). Accessories which contact with material are all made of stainless steel, no dead angles and easy to clean up.
6). Replacement between CO2 and O2 ensure almost no O2 in bottle, long filling pipe reduce O2 content to null.
7). Valve on-off system is driven by hydraulic cylinder, which starts on bottle signals.
8). High-speed and highly accurate bottling valves ensure no loss of liquid at high speed.
9). Equipped with CIP clean-in-place.
10). Bottom splint which fixed in the feed-out starwheel goes down in the manner of screw. Bottles can be changed without adjustment of height of conveyor chain.
11). Capping heads are magnetic constant-torque equipped to ensure capping quality with no damage.
12). Highly effective cap sorting and feed in system is protective for feed in and cap absence.
13). Equipped with overload system to safeguard machine and operators.
14). Touch screen operated.
15). Main electronic components( touch screen, PLC and frequency inverter) are imported products.
16). Components of pneumatic system are FESTO.
Main Technical parameters | |||||
Type |
BGF18-18-6 |
BGF24-24-8 |
BGF32-32-8 |
BGF40-40-10 |
BGF48-48-12 |
(B/H) Proouctive capacity |
3000 |
5000 |
8000 |
10000 |
12000 |
No. of rinsing, filling& amp; capping heads |
18-18-6 |
24-24-8 |
32-32-8 |
40-40-10 |
48-48-12 |
Suitable bottle height |
160-340 |
||||
Suitable bottle diameter |
Φ 50-Φ 100 |
||||
Water pressure supply |
0.25-0.3 |
||||
Filling way |
Pressure equality filling |
||||
Filling temperature |
0-5 |
||||
Filling pressure |
0.15-0.5 |
||||
Main power |
4 |
5.5 |
8 |
10 |
|
Total power |
5 |
7 |
12 |
||
Overall dimensions |
3012× |
3280× |
4430× |
4650× |
4987× |
Weight |
4000 |
5000 |
6800 |
8000 |
9500 |
