Anchor bolt tension meter is a measurement of the anchoring force. It has the feature of small size, light weight, easy to carry, easy to operate, and safety. It is widely used in coal, defense, tunnels and transportation and other tunneling operation. The hand pump can also be used alone as power source of small flow of high-pressure oil supply. The cylinder can also be used as a jack, using the digital pressure gauge to measure and read the measurement data accurately.
Structure:
Anchor bolt tension meter is connected by hollow jack and high-pressure hose. The hollow jack is composed by cylinder piston and reset spring. And the manual pump consists of the pump, plunger, gear and oil storage drum.
Technical parameters:
Maximum tension: 100KN-400KN (10T, 20T, 30T, 40T)
Maximum stroke: 100mm
Model |
10T anchor bolt tension meter |
20T anchor bolt tension meter |
Maximum tension |
10t |
20t |
Rated pressure |
55MPa |
55MPa |
Piston stroke (plus the return spring) |
20mm |
20mm |
Piston area |
18.5 cm² |
35 cm² |
Hand force(up to rated pressure) |
25kg |
25kg |
Weight |
8.25kg |
10.25kg |
